4-17
4.5.3 Removal and Installation
W
W
a
a
r
r
n
n
i
i
n
n
g
g
!
!
Before removing or installing a module, verify that the DC
power is turned off.
Removing the RS485 Connection Board
To remove the RS485 Connection Board from the RTU proceed as follows:
1. Turn off the DC power.
2. Disconnect all RS485 Connection Board input and output connections.
3. Pull out the RS485 Multiplexer by pressing the side snaps.
Installing a RS485 Connection Board
To install a RS485 Connection Board in the RTU proceed as follows:
1. Turn off the DC power.
2. Slide the RS485 Connection Board into its slot until the snaps click into place.
3. Reconnect the RS485 Adapter connection.
