7.2 Assembly Instructions:
1. Connect the + of the DC Power Source to the red fused line of the Line Filter.
2. Connect the – of the DC Power Source to the black line of the Line Filter.
3. Connect the opposite end of the Line Filter to the IRRInet-XL Main Power Cable
(FKN4469). Red-to-red, black-to-black and shield drain wire.
4. Turn on Power.
5. IRRInet-XL should be powered on.
7.3 DC Line Filter Field Replaceable Parts
Table 7-1 DC Line Filter Field Replaceable Parts
Part No. Description
FKN8024 DC Line Filter
6580283E03 Fuse Tube 5 Amp 250V
