5 - 14 MC70 User Guide
Using the MSR
The MSR3000 sample application illustrates how an application handles MSR input (refer to Symbol
Applications User’s Guide).
To use the MSR:
1. Attach the MSR to the EDA.
2. Power on the EDA.
3. Install the MC70 Demo application onto the EDA. The demo is available with the SMDK. See the MC70
Integrator Guide for more information.
4. Tap Start > MC70 Demo > Test Apps > MSR MC70 or MSR Cameo to start the sample application.
5. Swipe the magnetic stripe card through the MSR, with the magnetic stripe on the card facing down. Swipe
the card in either direction, from left to right or from right to left. For best results, gently press down on the
card while swiping to ensure contact with the bottom of the reader.
Figure 5-14 Magnetic Stripe Card Swiping
