Programming Reference B - 5
MSI 0 Check digits are sent.
1 No check digit is sent.
Example: An MSI bar code 4123, with a single check digit checked, is
transmitted as
]M1
4123.
D 2 of 5 0 No options specified at this time. Always transmit 0.
Example: A D 2 of 5 bar code 4123, is transmitted as
]S0
4123
UPC/EAN 0 Standard packet in full EAN country code format, which
is 13 digits for UPC-A, UPC-E, and EAN-13 (not
including supplemental data).
1 Two-digit supplement data only.
2 Five-digit supplement data only.
3 Combined data packet comprising 13 digits from a
UPC-A, UPC-E, or EAN-13 symbol and 2 or 5 digits from
a supplemental symbol.
4 EAN-8 data packet.
Example: A UPC-A bar code 012345678905 is transmitted as
]E0
0012345678905.
Bookland
EAN
0 No options specified at this time. Always transmit 0.
Example: A Bookland EAN bar code 123456789X is transmitted as
]X0
123456789X.
Code 11 0 Single check digit
1 Two check digits
3 Check characters validated but not transmitted.
Example: A Code 11 bar code 12345678901, with one check digit
enabled and transmit check digit enabled, is transmitted as
]H0
12345678901.
Table B-4
Modifier Characters (Continued)
Code Type Option Value Option
