Motorola Symbol CS3000 Series User Manual

Getting Started 1 - 23
Editing the Configuration File
Use a text editor such as Notepad to set configuration values in the Config.ini editable text file in the \Parameters
folder on the CS30XX. Table 1-1 lists the programmable contents of the file.
NOTE If you make errors while editing the Config.ini file, the file LOG.TXT is created in the \Parameters folder.
Consult this log file to determine the errors and make corrections.
Table 1-1 Config.ini File Content
Parameter Values Description Default
BarcodeFile String In batch mode, the name of the batch file
containing bar codes scanned.
BARCODES.TXT
BarcodeDB String Bar code database filename. If the
database file exists scanned bar codes are
checked against its content. If the bar
code exists within the database, the
scanner issues a positive beep, if not a
negative beep. To engage this mode,
create the BarcodeDB.txt file on the
CS30XX. Note that if this mode is
engaged, no bar code data is saved to the
scanner.
DBASE.TXT
BTPin String Default SPP PIN. 1234
BTName String Bluetooth device name used during
discovery.
CS3070:<serial
number>
BTProfile HID
SPP
Selected BT profile. HID
Mute On
Off
Mute the beeper. Off
Prefix Character Prefix character. <none>
Suffix Character Suffix character. 0x0D (CR)
Separator Character Separator character. ','
DateFormat MM/DD/YY
DD/MM/YY
MM/DD/YYYY
DD/MM/YYYY
Date format for batch data. Set to enable
date stamp . See Set Date on page 3-5 to
set the date.
Enter no value to disable the date stamp,
for example: “
DateFormat = “
MM/DD/YY
(Enabled)
TimeFormat 12h
24h
Time format for batch data. Set to enable
time stamp . See Set Time on page 3-5 to
set the time.
Enter no value to disable the time stamp,
for example: “
TimeFormat = “
24h
(Enabled)
