Motorola Symbol CS3000 Series User Manual

Getting Started 1 - 3
Charging the Scanner Battery
To charge the CS3000 series scanner, connect it to a host PC via the USB host cable or charging cradle. No power
supply is necessary. Charge time is approximately three hours for a fully discharged battery.
Charging via USB Host Cable
1. Remove the protective cover from the scanner.
Figure 1-4 Removing Protective Cover
2. Insert the mini-USB connector on the host cable in the interface port on the scanner.
3. Connect the other end of the host cable to a USB port on the host PC.
Figure 1-5 Connecting Scanner to Host PC
NOTE To check the battery charge status, hold the scan (+) button for 15 seconds. See Battery charge status in
Table 2-1 on page 2-3.

Motorola Symbol CS3000 Series Specifications

General

Brand	Motorola
Model	Symbol CS3000 Series
Category	Scanner
Language	English
