Motorola Symbol CS3000 Series User Manual

Scanning 2 - 3
Out of Range Behavior
If the scanner moves out of range of the host and does not re-pair with the host within the timeout period, it stores
data in a batch file. This data must be manually copied to the host. Within this timeout period, the scanner does not
decode and emits four error beeps in response to scan attempts.
User Interface Definitions
The scanner uses beeper and LED sequences to indicate various system events. Table 2-1 and Table 2-2 define
these sequences and events.
LED Indications
Table 2-1 LED Indications
Function Performed User Action LED Feedback Other
Scan attempt Press scan (+)
button
Flashing green Laser on
Successful bar code scan Solid green Laser off
Battery charge status Hold scan (+)
button 15 seconds
Flashing green Full charge (for 8 hours at 6
scans per minute)
Flashing amber Less than 8 hours but more
then one of operating time
Flashing red Less than 1 hour of operating
time
Delete bar code
(when in batch mode)
Press & hold
delete (-) button
Flashing amber Laser on
Successful bar code deletion Solid amber Laser off
Unsuccessful deletion - item doesn't
exist (when in batch mode)
Solid red Laser off
Clear all bar code data
(when delete (-) button enabled)
Press & hold
delete (-) button 3
seconds past scan
time
Flashing amber Laser on
Successful clear all Solid amber Laser off
Charge scanner Connect scanner
to a host PC USB
port
Flashing amber Scanner connects in mass
storage mode, auto-run
application on PC launches
Charge complete Solid green
