3.6.3 IEC Socket
Figure 7: Universal IEC-socket
The system is provided with a power cable with an IEC socket. This socket is a universal
socket which has been used in the most electronic-devices (PC, monitor, etc.).
3.6.4 Front- and side-panel
In the front panel , there is a USB port which can be used either to backup files or update
system with a new software and firmware. And there is also a small reset button which can
be used to restart the system manually.
Figure 8: Front panel
USB port
Reset button
