MP Aquinity 2 E - Calibration File (Calib.mcf)

Service setup
Page 63
u8_chart_time
0
option 7days/12months/24hr
u8_count_tank_swimmer
2
Max. count of swimmer count (Mo-Su)
u8_count_week_reboot
4
after 4x Sundays -> restart device
u8_device_type
3
0:AQ²E | 1:AQ²P | 2:AQ²P10 |3:Ast²
u8_device_version
0
0:RE | 1:AL | 2:LS | 3:AL,TI | 4:LS,TI
u8_di_port_intake_nc
4
DI-port water tap (NC)
u8_di_port_ps1
1
DI-port Pressure sensor
u8_di_port_regen
2
DI-port Regen
u8_di_port_salt
7
DI-port salt
u8_di_port_softener
8
DI-port Softener
u8_di_port_swimmer
3
DI-port swimmer
u8_di_port_tank_high
5
DI port tank level high
u8_di_port_tank_low
6
DI port tank level low
u8_hour_system_awake
5
at 5 am system start process
u8_hour_system_sleep
20
at 8 pm system goes to sleep
u8_init_value_array_size
5
init value -> array of 5 elements
u8_login_prio
0
0: no login / 1: user / 2:service
u8_login_prio_temp
0
Temp login prio
u8_p1_counter_max
9
Max. count of P1 (check every 30 min)
u8_q_setting
1
1/2/3/4 == q1 q2/q3/q4
u8_system_weekday_first
2
on (Monday) system starts working
u8_system_weekday_last
6
on (Friday) system stops working
u8_tool_option
0
Selector for tool
9.5.2 Calibration file (calib.mcf)
Ini-key
Default value
Help
b_desinf_status
F
TRUE -> desinfection is running
b_normal_start
F
FALSE -> first start is active
b_option_interval
T
FALSE -> permanent recirculation
b_option_q3_unit
F
FALSE -> µS/cm
b_option_regen
F
Not used
b_option_toc
F
TRUE -> TOC monitor is active
b_option_uf_mod
F
TRUE -> UF Modul is active
b_option_uS_control
F
TRUE -> option µS is active
b_option_uvpw
F
TRUE -> UV Lamp is active
b_option_uvt
F
TRUE -> UV in tank is active
dbl_q1_c_cond_max
230
For Calibration!
dbl_q1_c_cond_min
0
For Calibration!
dbl_q1_set_limit_max
20
max. allowed Q1
dbl_q2_c_cond_max
23
For Calibration!
dbl_q2_c_cond_min
0
For Calibration!
dbl_q2_set_limit_max
0,1
max. allowed Q2
dbl_q2_t_temp_max
90
For Calibration!
dbl_q2_t_temp_min
0
For Calibration!
dbl_q3_c_cond_max
2,3
For Calibration!
dbl_q3_c_cond_min
0
For Calibration!
dbl_q3_set_limit_max
0,07
max. allowed Q3
dbl_q3_t_temp_max
90
For Calibration!
dbl_q3_t_temp_min
0
For Calibration!
dbl_q4_c_cond_max
2,3
For Calibration!
dbl_q4_c_cond_min
0
For Calibration!
dbl_q4_t_temp_max
90
For Calibration!
