MP Aquinity 2 E - Page 67

Service setup
Page 62
dbl_sec_q1_out_error
1800
30 mins Q1 problem -> STOP
dbl_sec_q2_out_error
1800
Q2 is out of range (30 min) STOP
dbl_sec_q3_out_error
1800
Q3 < 0.045µS (30 mins) -> STOP
dbl_sec_q3_out_warning
180
Q3 > limit (3 mins) -> WARN
dbl_sec_release_pressure
8
Time to release pressure (8 sec)
dbl_sec_upw_desinf_sv6_close
10
SV6 close for (10 s) by disinfection
dbl_sec_upw_desinf_sv6_open
10
SV6 open for (10 s) by disinfection
dbl_sec_venting_upw
30
30 secs venting UPW
dbl_sec_venting_upw_sv6_close
5
Venting PW -> SV6 close (5 sec)
dbl_sec_venting_upw_sv6_open
5
Venting PW -> SV6 open (5 sec)
dbl_t3_limit_warning
40
T3 max. -> show Warning
dbl_t3_limit_warning_exit
38
T3 -> exit Warning
dbl_tank_level_desinf
70
minimal Tank (%) to start disinfection
dbl_tank_level_min_dry
10
10% Tank level dry-protection
dbl_tank_level_min_init
50
Min (50%) Tank level for first start
dbl_tank_level_min_tap
15
Min (15%) Tank level for water tap
dbl_tank_level_tool
50
minimal (%) Tank to start UPW/UF tool
str_backup_calib_file
\Had Disk\calib.mcf
Path of calibration file backup
str_backup_config_file
\Hard Disk\config.mcf
Path of config file backup
str_backup_file_high_density
\Hard Disk\data_high.dat
Path of data high file backup
str_backup_file_low_density
\Hard Disk\data_low.dat
Path of data low file backup
str_backup_file_mid_density
\Hard Disk\data_mid.dat
Path of data mid file backup
str_backup_file_op_hour
\Hard Disk\op_hour.dat
Path of operating hour file backup
str_backup_log_file
\Hard Disk\log_file.dat
Path of logfile backup
str_first_start_device
init_device_1
Default state of initial process
str_path_file_high_density
\NandFlash\data_high.dat
Path of data high file
str_path_file_low_density
\NandFlash\data_low.dat
Path of data low file
str_path_file_mid_density
\NandFlash\data_mid.dat
Path of data mid file
str_path_file_op_hour
\NandFlash\op_hour.dat
Path of operating hour file
str_path_log_file
\NandFlash\logfile.dat
Path of logfile
str_path_temp_file
\NandFlash\temp.dat
Path of temp file
str_standard_device
aquinity
Default state of normal process
str_tool_first_start
tool_first_start
Default state of first tool process
u16_mins_init_flush_ro
15
15 mins init FlushRO (AQ²P, AQ²P10)
u16_mins_init_flush_ro_edi
60
Init. FlushRO EDI for 60 mins (AQ²E)
u32_count_mins_desinfection
129600
Reminder of desinfection (3 Months)
u8_ai_bit_q1
0
0(12-bit), 1(14-bit), 2(16-bit), 3(18-bit)
u8_ai_bit_q2
0
0(12-bit), 1(14-bit), 2(16-bit), 3(18-bit)
u8_ai_bit_q3
0
0(12-bit), 1(14-bit), 2(16-bit), 3(18-bit)
u8_ai_bit_q4
0
0(12-bit), 1(14-bit), 2(16-bit), 3(18-bit)
u8_ai_bit_t2
0
0(12-bit), 1(14-bit), 2(16-bit), 3(18-bit)
u8_ai_bit_t3
0
0(12-bit), 1(14-bit), 2(16-bit), 3(18-bit)
u8_ai_bit_t4
0
0(12-bit), 1(14-bit), 2(16-bit), 3(18-bit)
u8_ai_bit_tank
0
0(12-bit), 1(14-bit), 2(16-bit), 3(18-bit)
u8_ai_port_q1
1
AI-port Q1
u8_ai_port_q2
3
AI-port Q2
u8_ai_port_q3
5
AI-port Q3
u8_ai_port_q4
7
AI-port Q4
u8_ai_port_t2
4
AI-port T2
u8_ai_port_t3
6
AI-port T3
u8_ai_port_t4
8
AI-port T4
u8_ai_port_tank
13
AI-port tank
u8_chart_sensor
0
Display sensors for Service
u8_chart_sensor_2
0
Display sensors for Customer
