MP Aquinity 2 E - Page 88

R001
290-0226
E001
921-0225
P001
820-0816
Q002
921-0372
Q003
921-0372
P002
820-0816
Q004
921-0372
PSA-001
820-0608
V001
921-0545
FA007 190-0013
SV002
830-0531
SV003
830-0504
Q001
820-0010
Block
810-0483
SV004
830-0531
SV005
830-0504
SV001
830-0504
PRV001
830-0500
SV006
830-0504
UV002
921-0138
FA001 (black)
290-0065
FA002 (red)
290-0218
FA005 (blue)
190-0087(LS)/88(AL)
PCB-IO
921-0542
PCB-Conductivity
921-0498
2x 24V
820-0827
12V
820-0844
CPU with Display
820-0725
FrontPanel
810-0512
Housing
810-0462
2x SidePanel
810-0514
Aquinity²E rev.2
Exploded view v.1.0.
2018.04.11HaSFull System
Manometer
PI001
900-1422
Cooling + EDI supply
820-0235
USB
860-1996
Reset
860-2002
Ballast UV system 230V
820-0123
Ballast UV system 110V
(optional)
921-0515
4x Footing
810-0525
4x Flat Washer
860-0043
8x Magnet
810-0555
UF-Modul
FA006
190-0052
