MPI 40 Series - Page 10

TABLE OF CONTENTS (continued)
SECTION 6 OPTIONAL CONFIGURATION
6.1
6.2
6.3
6.4
6.5
6.6
6.7
6.8
INTRODUCTION
DRIVE SELECT RECONFIGURATION •
SELECT DRIVE WITHOUT LOADING HEADS OR ENABLING STEPPER MOTOR
SELECT DRIVE AND ENABLE STEPPER MOTOR WITHOUT LOADING HEADS
HARD SECTORED DISKETTE WITH 32/16/8 SECTORS • • • •
FM SEPARATED DATA AND CLOCK
EXTERNAL MOTOR ON •
WRITE CURRENT SWITCH •
Page
6-1
6-2
6-4
6-5
6-6
6-6
6-7
6-8
APPENDIX A RECOMMENDED SPARE PARTS LIST • • • • • • • • • • • • • • • A-1
APPENDIX B DRAWINGS AND SCHEMATICS • • • • • • • • • • • • • • • • • B-1
viii
