SECTION 4
MAINTENANCE
4.1 INTRODUCTION
This section contains preventive maintenance procedures, component
removal/replacement procedures, and adjustment and measurement procedures.
The material is referenced to drawings located throughout the text, a spare
parts list located in Appendix A, and drawings and schematics located in
Appendix B. Adjustment procedures will be required if parts are changed due to
malfunction and measurements should be made periodically to ensure data
quality or if malfunctions are suspected. It is recommended that a master
alignment diskette be kept and that each alignment be verified to the master.
Table 4-1: Section Index
Topic
Paragraph
General Information
4.2
Preventive Maintenance
4.3
Recommended Tools and Test Equipment
4.4
Removal/Replacement Procedures
4.5
Adjustment Procedures
4.6
Measurement Procedures
4.7
4.2 GENERAL INFORMATION
The following statements are applicable to all facets of drive
maintenance:
A. Do not remove any components or the printed circuit boards or
connect or disconnect any plugs while power is applied to the
drive.
B. Component-location instructions are referenced as viewed from the
front of the drive.
