3. 7
.2
Data Recovery
Data
recovery
refers
to
the
retrieving
of
data
from
the
flexible
diskette.
The
following
paragraphs
describe
the
problems
asso-
ciated
with
data
recovery
and methods
to
ensure
data
reliability.
3.7.2.1 Bit Shift
Bit
shift
refers
to
the
displacement
of
a
bit,
as
detected
by
the
drive,
from
its
nominal
position.
The
causes
of
bit
shift
are
manifold
--
R/W
head
resolution,
media
resolution,
diskette
speed
variation,
signal-to-noise
ratio
of
read
head
output.
3.7.2.2 Write Precompensation
Certain
data
patterns
cause
more
bit
shift
than
other
patterns.
This
bit
shift
is
predictable
and
can
thus
be
partially
compen-
sated
for.
For
example,
if
it
is
known
that
a
bit
will
be
shifted
by
500
ns
when
it
is
read
back,
then
the
bit
can
be
deliberately
written
200
ns
early.
This
would
give
a
bit
shift
of
about
350
ns
when
it
is
read
back.
This
method
of
reducing
bit
shift
is
called
write
precompensation.
Bit
shift
is
greater
on
the
inner
tracks
of
the
diskette
than
on
the
outer
tracks,
making
write
precompensation
necessary
only
on
the
inner
tracks.
Write
precomp
of
250
to
300
ns
should
be
used
on
tracks
44
through
77.
If
due
to
controller
limitations,
write
precomp must
be
used
on
all
tracks,
then
125
to
150
ns
should
be
used.
3.
7 .2.3 Data Separation
Data
separation
refers
to
the
separating
of
the
composite
data
coming from
the
drive
into
separate
clock
and
separate
data
bits.
Normally
in
a
read
operation
raw
read
data
or
encoded
data
is
provided
to
the
controller
and
data
separation
or
decoding
is
done
by
the
controller.
But
as
an
option
for
FM
code,
separated
data
and
clock
are
provided
along
with
.the raw
read
data.
For
MFM
encoded
data,
decoding
should
be
done by
the
controller
using
a
suitable
phase
lock
loop
circuit
or
else
maximum
read
channel
margin
(
and
hence
the
specified
soft
error
rate
)
cannot
be
achieved.
See
Figure
3-9
for
FM
encoded
data
separ-
ation.
The
optional
data
separator
properly
separates
data
and
clock
bits
through
the
soft-sectored
IBM
standard
format
and
address
mark
areas.
In
MFM
recording,
data
bits
and
clock
bits
are
subject
to
the
same
amount
of
bit
shift.
A
PLL
separator
with
a
50%
data
window and a
50%
clock
window
should
be
used.
3-25
