Appendix
The data in this manual are not binding and may be changed by the manufacturer without notice. Reproduction of this manual, even partial, is strictly prohibited.
ALPHANUMERIC STRING
PROBES
POS. VALUE DESCRIPTION
VERSION 1-2-3 H H
NN
SN SN
SSN SSN
REFRIGERANT 4 3 R410A
UNIT AMBIENT TEMPERATURE 5 0 STANDARD
1-20°C
EVAPORATOR 6 A PLATE EVAPORATOR
B SHELL AND TUBE EVAPORATOR
ELECTRONIC THERMOSTATIC
VALVE
70NO
1YES
HYDRAULIC UNIT 8 0 NONE
1P2
2P2+P2
3STORAGE + P2
4 STORAGE + P2+P2
6P3
7P3+P3
8STORAGE + P3
9 STORAGE + P3+P3
EVAP. FREEZE PROTECTION 9 0 NO
1YES
COMPRESSOR SHUT-OFF VALVES 10 0 NO
1YES
HEAT RECOVERY 11 0 NO
2 100% HEAT RECOVERY
4 20% DESUPERHEATER
PREPAINTED CONDENSING COILS 12 0 NO
1YES
CONDENSING COILS PROTECTION 13 0 NO
1YES
FAN CONTROL 14 0 3 STEPS
1 ELECTRONIC SPEED CONTROL
POWER FACTOR CORRECTION
CAPACITORS
15 0 NO
1YES
PHASE MONITOR 16 A YES
REMOTE CONTROL 17 B NO
CSIMPLE
COMPRESSOR CRANKCASE HEATER 18 1 YES
Probe-Transducer Description Function
-BHP1 High pressure transducer 1 P
-BHP2 High pressure transducer 2 P
-BLP1 Low pressure transducer 1 P
-BLP2 Low pressure transducer 2 P
-BEWIT Evaporator water inlet temperature T
-BEWOT Evaporator water outlet temperature T
-BTWOT Tank water outlet temperature T
-BAT1 Ambient Temperature 1 T
-BAT2 Ambient Temperature 2 T
-BRWOT Heat recovery water outlet temperature T
-BRWIT Heat recovery water inlet temperature T
