0134
ST10 Time band setpoint Band 4 start 18.0 °C 0÷23 0÷59
Chiller setpoint 7 °C 4÷20
Heat pump setpoint 45 °C 25÷55
0135
ST11 Chiller adjustable
setpoint
Minimum setpoint
(4mA)
4°C 4÷20
0136
Maximum setpoint
(20mA)
10 °C 4÷20
0137
ST12 Heat pump
adjustable setpoint
Minimum setpoint
(4mA)
40 °C 25÷55
0138
Maximum setpoint
(20mA)
45 °C 25÷55
Ref. 02 HAS T 070 HAS T 080 HAS T 090 HAS T 100 HAS T 110 HAS T 120 HAS T 130 HAS T 140
Ref. 020 C001-C001 C002-C002 C002-C002 C002-C002 C003-C003 C003-C003 C004-C004 C004-C004
Ref. 021 C001-C001 C001-C001 C002-C001 C002-C002 C002-C002 C003-C003 C003-C003 C004-C004
Table 1
Ref. 03 N SN SSN
Table 2
Ref. 010 yes yes yes yes yes
Ref. 011 no no yes no yes
Ref. 010 yes yes yes yes
Ref. 011 no yes no yes
Table 3
Ref. Code Mask Field Level Value UDM Range
