ST10 C Defines the probe for temperature control of the unit in heat pump
mode:
0= Evaporator inlet NTC temperature probe
1= Evaporator outlet NTC temperature probe no. 1
2= Evaporator outlet NTC temperature probe no. 2
3= Common evaporator outlet NTC temperature probe
4= Remote terminal temperature probe no. 1
5= Remote terminal temperature probe no. 2
6= Common condenser water inlet NTC temperature probe
7= Circuit n° 1 condenser water inlet NTC temperature probe
8= Circuit n° 2 condenser water inlet NTC temperature probe
9= Circuit n° 1 condenser water outlet NTC temperature probe
10= Circuit n° 2 condenser water outlet NTC temperature probe
11= Common condenser water outlet NTC temperature probe
ATTENTION
If the same temperature control is required both in chiller
mode and in heat pump mode, set the same value in parameters
ST09 and ST10.
011
ST11 S Defines the temperature control type:
0= Proportional
1= Neutral zone
01
Pr1 U User password 0 999
Pr2 S Service password 0 999
Pr3 C Manufacturer password 0 999
Display message
dP01 S Upper display default presentation.
0= No visualization
1= Temperature probe of the evaporator water inlet (EIn label)
3= Temperature probe of the common evaporator water outlet
(EOut label)
016
dP02 S Lower display default presentation.
0= No visualization
1= Temperature probe of the evaporator water inlet (Label EIn)
3= Temperature probe of the common evaporator water outlet
(EOut label)
020
Forced display message
dP03 C Lower / upper display default presentation:
0= Configurable presentation
1= Upper display evaporator IN / lower display evaporator OUT
2= Upper display condenser IN / lower display condenser OUT
3= Upper display condensing temperature / pressure / lower
display evaporation pressure.
03
Remote terminals display forced presentation
dP04 C Remote terminal no.1 upper display default presentation:
0= The display mode depends on the value of parameters dP01 -
dP02 - dP03
1= The upper display shows the temperature measured by the
NTC probe on board remote terminal no.1
01
dP05 C Remote terminal no.2 upper display default presentation:
0= The display mode depends on the value of parameters dP01 -
dP02 - dP03
1= The upper display shows the temperature measured by the
NTC probe on board remote terminal no.2
01
dP06 S Visograph: first displayed probe selection 0 35
dP07 S Visograph: second displayed probe selection 0 35
dP08 S Visograph: third displayed probe selection 0 35
dP09 S Visograph: fourth displayed probe selection 0 35
Parameter Level Description Min. Max. UM Resolution
