OPERATING AND MAINTENANCE MANUAL
Chapter 7 - Electronic controller
TAEevo Tech 015÷802 60 Hz UL
79
The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited
EN
ENGLISH
Chiller mode
CF77 C Chiller mode:
1= With compressors
2= Only FC
3= With compressors and FC
13
I/O expansion enabling
CF78 C I/O expansion enabling:
0= Not enabled
1= Enabled
01
Electronic expansion valve driver enabling
CF79 C Circuit 1 electronic expansion valve enabling:
0= Not enabled
1= Enabled
01
CF80 C Circuit 2 electronic expansion valve enabling:
0= Not enabled
1= Enabled
01
CF81 C Electronic expansion valve address 1 15
CF82 C Evaporation probe positioning selection:
0= In Ichill controller
1= In IEV valve driver
01
CF83 C Temperature control start delay after transmitting valve start
command
0 250 Sec.
CF84 C Visograph keypad presence:
0= No
1= Yes
01
I/O expansion configuration
EI01 C I/O expansion board address 0 15
EI02 C PB1 configuration
If configured as a digital input.
0
o 1
28
c75
EI03 C PB2 configuration
If configured as a digital input.
0
o 1
28
c75
EI04 C PB3 configuration
If configured as a digital input.
0
o 1
35
c75
EI05 C PB4 configuration
If configured as a digital input.
0
o 1
35
c75
EI06 C PB5 configuration
If configured as a digital input.
0
o 1
35
c75
EI07 C PB6 configuration
If configured as a digital input.
0
o 1
28
c75
EI08 C PB7 configuration
If configured as a digital input.
0
o 1
28
c75
EI09 C PB8 configuration
If configured as a digital input.
0
o 1
28
c75
I/O expansion probes offset
EI10 C PB1 offset -12.0
-21
12.0
21
°C
°F
Dec
Int
EI11 C PB2 offset -12.0
-21
12.0
21
°C
°F
Dec
Int
EI12 C PB3 offset -5.0
-72
5.0
72
Bar
Psi
Dec
Int
EI13 C PB4 offset -5.0
-72
5.0
72
Bar
Psi
Dec
Int
EI14 C PB5 offset -12.0
-21
12.0
21
°C
°F
Dec
Int
EI15 C PB6 offset -12.0
-21
12.0
21
°C
°F
Dec
Int
EI16 C PB7 offset -12.0
-21
12.0
21
°C
°F
Dec
Int
EI17 C PB8 offset -12.0
-21
12.0
21
°C
°F
Dec
Int
Parameter Level Description Min. Max. UM Resolution
