Chapter 7 - Electronic controller
TAEevo Tech 015÷802 60 Hz UL
80
The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited
ENGLISH
EN
EI18 C Transducer PB3 pressure value at 4mA - 0.5V. -1.0
-14
50.0
725
Bar
Psi
Dec
Int
EI19 C Transducer PB3 pressure value at 20mA - 4.5V. -1.0
-14
50.0
725
Bar
Psi
Dec
Int
EI20 C Transducer PB4 pressure value at 4mA - 0.5V. -1.0
-14
50.0
725
Bar
Psi
Dec
Int
EI21 C Transducer PB4 pressure value at 20mA - 4.5V. -1.0
-14
50.0
725
Bar
Psi
Dec
Int
EI22 C Transducer PB5 pressure value at 4mA - 0.5V. -1.0
-14
50.0
725
Bar
Psi
Dec
Int
EI23 C Transducer PB5 pressure value at 20mA - 4.5V. -1.0
-14
50.0
725
Bar
Psi
Dec
Int
I/O expansion digital inputs
EI24 C ID1 configuration 0 -o1 c75
EI25 C ID2 configuration 0 -o1 c75
EI26 C ID3 configuration 0 -o1 c75
EI27 C ID4 configuration 0 -o1 c75
EI28 C ID5 configuration 0 -o1 c75
EI29 C ID6 configuration 0 -o1 c75
EI30 C ID7 configuration 0 -o1 c75
EI31 C ID8 configuration 0 -o1 c75
EI32 C ID9 configuration 0 -o1 c75
I/O expansion relay inputs
EI33 C RL1 configuration 0 -o1 c74
EI34 C RL2 configuration 0 -o1 c74
EI35 C RL3 configuration 0 -o1 c74
EI36 C RL4 configuration 0 -o1 c74
EI37 C RL5 configuration 0 -o1 c74
EI38 C RL6 configuration 0 -o1 c74
EI39 C RL7 configuration 0 -o1 c74
I/O expansion proportional outputs
Modulating outputs
EI40 C Selection of analogue outputs signal 0..10V or 4..20mA 0 1
EI41 C Proportional output OUT 1:
0= Output disabled
1= Evaporator pump with modulating operation
2= Modulating output for Free cooling
3= Not used
4= 0...10V auxiliary output no. 1
5= 0...10V auxiliary output no. 2
6= Modulating output compressor 1 circuit no. 1
7= Modulating output compressor 1 circuit no. 2
8= 0...10V condensing fans circuit no. 1
9= 0...10V condensing fans circuit no. 2
Relay controlling ON / OFF output
0
o 1
9
c50
EI42 C Proportional output OUT 2:
0= Output disabled
1= Evaporator pump with modulating operation
2= Modulating output for Free cooling
3= Not used
4= 0...10V auxiliary output no. 1
5= 0...10V auxiliary output no. 2
6= Modulating output compressor 1 circuit no. 1
7= Compressor 1 modulating output circuit no. 2
8= 0...10V condensing fans circuit no. 1
9= 0...10V condensing fans circuit no. 2
10= Condensing fans PWM output circuit 1
11= Condensing fans PWM output circuit 2
Relay controlling ON / OFF output
0
o 1
11
c50
