OPERATING AND MAINTENANCE MANUAL
Chapter 7 - Electronic controller
TAEevo Tech 015÷802 60 Hz UL
81
The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited
EN
ENGLISH
EI43 C Proportional output OUT 3:
0= Output disabled
1= Evaporator pump with modulating operation
2= Modulating output for Free cooling
3= Not used
4= 0...10V auxiliary output no. 1
5= 0...10V auxiliary output no. 2
6= Modulating output compressor 1 circuit no. 1
7= Modulating output compressor 1 circuit no. 2
8= 0...10V condensing fans circuit no. 1
9= 0...10V condensing fans circuit no. 2
10= Condensing fans PWM output circuit 1
11= Condensing fans PWM output circuit 2
Relay controlling ON / OFF output
0
o 1
11
c50
Pr1 U User password 0 999
Pr2 S Service password 0 999
Pr3 C Manufacturer password 0 999
Dynamic setpoint
Sd01 U Dynamic setpoint max increase in chiller mode
Establishes the maximum variation of the working setpoint in
chiller mode.
-30.0
-54
30.0
54
°C
°F
Dec
Int
Sd02 C Max dynamic setpoint increase in heat pump mode
Establishes the maximum variation of the working setpoint in
heat pump mode.
-30.0
-54
30.0
54
°C
°F
Dec
Int
Sd03 U Dynamic setpoint ambient air temperature setting in chiller mode. -50.0
-58
110.0
230
°C
°F
Dec
Int
Sd04 C Dynamic setpoint ambient air temperature setting in heat pump
mode.
-50.0
-58
110.0
230
°C
°F
Dec
Int
Sd05 U Dynamic setpoint ambient air temperature differential in chiller
mode.
-30.0
-54
30.0
54
°C
°F
Dec
Int
Sd06 C Dynamic setpoint ambient air temperature differential in heat
pump mode.
-30.0
-54
30.0
54
°C
°F
Dec
Int
Sd07 C Dynamic setpoint max increase in chiller mode auxiliary
analogue output 1.
-30.0
-54
30.0
54
°C
°F
Dec
Int
Sd08 C Dynamic setpoint max increase in heat pump mode auxiliary
analogue output 1.
-30.0
-54
30.0
54
°C
°F
Dec
Int
Sd09 C Dynamic setpoint ambient air temperature setting in chiller mode
auxiliary analogue output 1.
-50.0
-58
110.0
230
°C
°F
Dec
Int
Sd10 C Dynamic setpoint ambient air temperature setting in heat pump
mode auxiliary analogue output 1.
-50.0
-58
110.0
230
°C
°F
Dec
Int
Sd11 C Dynamic setpoint ambient air temperature differential in chiller
mode auxiliary analogue output 1.
-30.0
-54
30.0
54
°C
°F
Dec
Int
Sd12 C Dynamic setpoint ambient air temperature differential in heat
pump mode auxiliary analogue output 1.
-30.0
-54
30.0
54
°C
°F
Dec
Int
Sd13 C Dynamic setpoint max increase in chiller mode auxiliary
analogue output 2.
-30.0
-54
30.0
54
°C
°F
Dec
Int
Sd14 C Dynamic setpoint max increase in heat pump mode auxiliary
analogue output 2.
-30.0
-54
30.0
54
°C
°F
Dec
Int
Sd15 C Dynamic setpoint ambient air temperature setting in chiller mode
auxiliary analogue output 2.
-50.0
-58
110.0
230
°C
°F
Dec
Int
Sd16 C Dynamic setpoint ambient air temperature setting in heat pump
mode auxiliary analogue output 2.
-50.0
-58
110.0
230
°C
°F
Dec
Int
Sd17 C Dynamic setpoint ambient air temperature differential in chiller
mode auxiliary analogue output 2.
-30.0
-54
30.0
54
°C
°F
Dec
Int
Sd18 C Dynamic setpoint ambient air temperature differential in heat
pump mode auxiliary analogue output 2.
-30.0
-54
30.0
54
°C
°F
Dec
Int
Sd19 C Dynamic setpoint max increase in chiller mode auxiliary relay 1. -30.0
-54
30.0
54
°C
°F
Dec
Int
Sd20 C Dynamic setpoint max increase in heat pump mode auxiliary
relay 1.
-30.0
-54
30.0
54
°C
°F
Dec
Int
Parameter Level Description Min. Max. UM Resolution
