OPERATING AND MAINTENANCE MANUAL
Chapter 7 - Electronic controller
TAEevo Tech 015÷802 60 Hz UL
91
The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited
EN
ENGLISH
FA03 C Fans max speed start time after ON (TRIAC). At each start,
irrespective of the condensing temperature / pressure the fan is
fed at maximum voltage for time FA03 after which the fan
continues to run at the speed set by the regulator.
0 250 Sec
FA04 C Fans staggering 0 8 Micro-
seconds
250ms
FA05 C Single or separate condensing fan:
0= Single
1= Separate
01
FA06 C Pre-ventilation in chiller mode before compressor ON.
Used to set a run time of the fans at maximum speed in chiller
mode before compressor start, in order to anticipate the sudden
condensing temperature / pressure increase (resulting from
starting of the compressor) and improve temperature control.
0 250 Sec
Operation in chiller mode
FA07 C Minimum operating speed of fans in chiller mode.
Used to set a minimum value of the proportional control of the
fans in chiller mode.
Expressed as a percentage from 0 to 100% of the maximum
permitted voltage.
0 100 %
FA08 C Maximum operating speed of fans in chiller mode.
Used to set a maximum value of the proportional control of the
fans in chiller mode.
Expressed as a percentage from 0 to 100% of the maximum
permitted voltage.
0 100 %
FA09 C Proportional control:
Used to set the condensing temperature / pressure value in chiller
mode corresponding to the minimum fan speed.
Step control
1st STEP SET Used to set the condensing temperature / pressure
value in chiller mode to which operation in ON corresponds of the
relay output configured as 1st condensing fan speed step.
0.0
0
50.0
725
Bar
Psi
Dec
Int
FA10 C Proportional control:
Used to set the condensing temperature / pressure value in chiller
mode corresponding to the maximum fan speed.
Step control
2nd STEP SET Used to set the condensing temperature / pressure
value in chiller mode to which operation in ON corresponds of the
relay output configured as 2nd condensing fan speed step.
0.0
0
50.0
725
Bar
Psi
Dec
Int
FA11 C Proportional control:
Fans control proportional band in chiller mode.
Used to set a temperature / pressure differential with a
corresponding change in fan speed from minimum to maximum.
Step control
With Par. FA01 = 2 or 3 this becomes the differential on the step
of circuit 1 in chiller mode.
0.1
1
14.0
203
Bar
Psi
Dec
Int
FA12 C Proportional control:
CUT-OFF differential in chiller mode.
Used to set a temperature / pressure differential in chiller mode
for stopping of the fan.
Step control
With Par. FA01 = 2 or 3 this becomes the differential on the step
of circuit 2 in chiller mode.
0.1
1
14.0
203
Bar
Psi
Dec
Int
FA13 C Override CUT-OFF in chiller mode.
Used to set a temperature / pressure differential in chiller mode at
which the fan remains at minimum speed.
0.1
1
14.0
203
Bar
Psi
Dec
Int
FA14 C CUT-OFF delay time.
Used to set a time lag for activation of the CUT-OFF function at
starting of the fans.
If at the compressor start the proportional controller requests fan
cut-off and FA14 is different from 0, the fan will be forced to the
minimum speed for the set time.
If FA14=0 the function is not enabled.
0 250 Sec
Parameter Level Description Min. Max. UM Resolution
