US42 C Auxiliary analogue output 2 summer differential 0.1
0
25.0
45
°C
°F
Dec
Int
US43 C Auxiliary analogue output 2 winter differential 0.1
0
25.0
45
°C
°F
Dec
Int
US44 C Auxiliary analogue output 2 minimum value 0 US45 %
US45 C Auxiliary analogue output 2 maximum value US44 100 %
Modulating output minimum value
US46 C Forcing to 0 of the analogue output below the minimum value 0 1
Modulating evaporator pump
US47 C Select probe 1 for modulating pump operation in chiller mode 0 20
US48 C Select probe 2 for modulating pump operation in chiller mode 0 20
US49 C Set point for modulating pump maximum speed in chiller mode 30.0
-58
110.0
230
°C
°F
Dec
Int
US50 C Modulating pump regulation proportional band in chiller mode 0.0
0
25.0
45
°C
°F
Dec
Int
US51 C Modulating pump minimum speed in chiller mode 0 100 %
US52 C Modulating pump maximum speed in chiller mode 0 100 %
US53 C Select probe 1 for modulating pump operation in heat pump mode 0 20
US54 C Select probe 2 for modulating pump operation in heat pump mode 0 20
US55 C Set point for modulating pump maximum speed in heat pump
mode
-50.0
-58
110.0
230
°C
°F
Dec
Int
US56 C Modulating pump regulation proportional band in heat pump
mode
0.1
0
25.0
45
°C
°F
Dec
Int
US57 C Modulating pump minimum speed in heat pump mode 0 100 %
US58 C Modulating pump maximum speed in heat pump mode 0 100 %
US59 C Modulating pump speed during free cooling 0 100 %
US60 C Modulating pump speed with compressor off 0 100 %
Auxiliary outputs enabling
US61 C Auxiliary relay 1 output enable:
1= Chiller only
2= Heat pump only
3= Chiller and heat pump
13
US62 C Auxiliary relay 2 output enable:
1= Chiller only
2= Heat pump only
3= Chiller and heat pump
13
US63 C Auxiliary relay 1 analogue output enable:
1= Chiller only
2= Heat pump only
3= Chiller and heat pump
13
US64 C Auxiliary relay 2 analogue output enable:
1= Chiller only
2= Heat pump only
3= Chiller and heat pump
13
Pr1 U User password 0 999
Pr2 S Service password 0 999
Pr3 C Manufacturer password 0 999
Condensing fans
FA01 C Fans control:
0= Absent
1= Always on
2= ON/OFF steps control
3= Continuous ON/OFF steps control
4= Proportional speed regulator
04
FA02 C Fans operating mode:
0= Dependent on compressor
1= Independent on compressor
01
Parameter Level Description Min. Max. UM Resolution
