MTA TAEevo Tech 101 - Page 90

OPERATING AND MAINTENANCE MANUAL
Chapter 7 - Electronic controller
TAEevo Tech 015÷802 60 Hz UL
89
The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited
EN
ENGLISH
US20 C Auxiliary relay 2 winter differential 0.1
0
25.0
45
°C
°F
Dec
Int
US21 C Auxiliary relays maximum activation time 0 250 Min
Auxiliary 0...10V proportional output 1
US22 C Operation of auxiliary proportional output 1:
0= Not enabled
1= Direct action always enabled
2= Direct action enabled only with unit in ON
3= Reverse action always enabled
4= Reverse action enabled only with unit ON
04
US23 C Configuration of analogue input for management of auxiliary
output 1 makes it possible to select probe from PB1 to PB10 for
management of the function
120
US24 C Auxiliary analogue output 1 minimum summer set -50.0
-58
0.0
0
US26 °C
°F
Bar
Psi
Dec
Int
Dec
Int
US25 C Auxiliary analogue output 1 maximum summer set US26 110.0
230
50.0
725
°C
°F
Bar
Psi
Dec
Int
Dec
Int
US26 C Auxiliary analogue output 1 summer set US24 US25 °C
°F
Bar
Psi
Dec
Int
Dec
Int
US27 C Auxiliary analogue output 1 minimum winter set -50.0
-58
US29 °C
°F
Dec
Int
US28 C Auxiliary analogue output 1 maximum winter set US29 110.0
230
°C
°F
Dec
Int
US29 C Auxiliary analogue output 1 winter set US27 US28 °C
°F
Dec
Int
US30 C Auxiliary analogue output 1 summer differential 0.0
0
25.0
45
°C
°F
Dec
Int
US31 C Auxiliary analogue output 1 winter differential 0.0
0
25.0
45
°C
°F
Dec
Int
US32 C Auxiliary analogue output 1 minimum value 0
US33 %
US33 C Auxiliary analogue output 1 maximum value US32 100 %
Auxiliary 0...10V proportional output 2
US34 C Operation of auxiliary proportional output 2 (see function and
auxiliary output diagrams):
0= Not enabled
1= Direct action always enabled
2= Direct action enabled only with unit in ON
3= Reverse action always enabled
4= Reverse action enabled only with unit ON
04
US35 C Configuration of analogue input for management of auxiliary
output 2 makes it possible to select probe from PB1 to PB10 for
management of the function
120
US36 C Auxiliary analogue output 2 minimum summer set -50.0
-58
US38 °C
°F
Dec
Int
US37 C Auxiliary analogue output 2 maximum summer set US38 110.0
230
°C
°F
Dec
Int
US38 C Auxiliary analogue output 2 summer set US36 US37 °C
°F
Dec
Int
US39 C Auxiliary analogue output 2 minimum winter set -50.0
-58
US41 °C
°F
Dec
Int
US40 C Auxiliary analogue output 2 maximum winter set US41 110.0
230
°C
°F
Dec
Int
US41 C Auxiliary analogue output 2 winter set US39 US40 °C
°F
Dec
Int
Parameter Level Description Min. Max. UM Resolution
