multicomp pro HDS-N Series User Manual

8-Advanced Function of Oscilloscope
62
through Playback and Save functions.
Four record modes: Record, Play back, Storage, OFF.
Record：Record the waveforms up until the set number of frames at specified time intervals.
Record menu list：
Menu Setting Instruction
Mode
Record
Play back
Storage
OFF
Select record mode.
Select play back mode.
Select storage mode.
Turn off all recorder functions.
End frame 1-1000
Set number of record frames.
Operate
Play
Stop
Press to start recording.
Press to stop recording.
Interval
1 ms - 1000
s
Set time interval between record frames.
－－＞
1/2
To next menu
Refreshed
ON
OFF
The waveforms are in the state of refreshing when recording.
The waveforms stop refreshing when recording.
Direction
Increase
Decrease
The value increases from that of end frame to time interval
The value decreases from that of end frame to time interval
－－＞
1/2
Back to previous menu.
Note: Both the waveforms are recorded at record mode. If one channel is off when recording, the
channel data is not available at Playback mode.
Play back: Play back the recorded waveforms.
Play back menu list：
Menu Setting Instruction
Play mode
Loop
Single
Set repeat play mode.
Set single time play mode.
Operate
Play
Stop
Press to start playback.
Press to stop playing.
Interval 1ms-20s Set up interval value between frames.
