multicomp pro HDS-N Series User Manual

10-Appendix
78
Cymometer
Signal system and line/field
frequency (Video triggering mode)
Support the NTSC, PAL and SECAM broadcasting systems
of any field or line frequency.
Readout resolution 6 digits
Frequency range AC coupling, 2 Hz to full bandwidth
Single source
 When the triggering mode is edge triggering, it is a one
channel Cymometer.
 When the triggering mode is video triggering，the
Cymometer will not work..
Measurement
Cursor measurement
Voltage difference (△V) and time difference (△T) between cursors
Auto measurement
Peak-to-peak value, average value, root mean square value, frequency ,
period，Vmax, Vmin，
Vtop, Vbase, Vamp, Overshoot, Preshoot, Rise
Time, Fall Time, +Width, -Width, +Duty, -Duty.
Probe
1X position 10X position
Bandwidth Up to 6 MHz (DC) Up to full bandwidth (DC)
Attenuation rate 1: 1 10: 1
Compensation range 15 pf – 35 pf
Input resistance
1 MΩ ± 2％ 10 MΩ ± 2％
Input Capacitance
85 pf – 115 pf
14.5 pf - 17.5 pf
Input voltage
＜
200 V DC + Peak AC
＜
600 V DC + Peak AC
10.1.2 Meter
Voltage (VDC)
Input Impedance: 10 MΩ.
Max. Input Voltage: 1000 V (DC or AC peak value)
Range
Accuracy
Resolution
400.0 mv
±1%±2 digits
100 uV
4.000 V
1 mV
40.00 V 10 mV
400.0 V 100 mV
1000 V 1 V
