multicomp pro HDS-N Series User Manual

10-Appendix
77
Sampling rate and delay
time accuracy
±100ppm
(any time interval which is equal to or larger than 1ms)
Time interval ( △
T)measurement accuracy
（full bandwidth）
Single:
±(1 sampling interval time +100ppm×reading+0.6ns)
>average 16 :
±(1 sampling interval time +100ppm×reading+0.4ns)
Vertical
Analog digital converter
（A/D）
With the resolution of 8 bits,
make sampling on both channels
synchronously.
Displacement range
±2 V(5 mV/div ~ 200 mV/div),
±50 V(500 mV/div ~5 V /div)
Analog bandwidth
MP720014 20 MHz
MP720015 60 MHz
Single bandwidth Full bandwidth
Low frequency response
（AC coupling, -3dB）
≥10 Hz（at the BNC ）
Rise time（typical one at the
BNC）
MP720014
≤17.5 ns
MP720015
≤ 5.8 ns
DC gain accuracy
±3%
DC measurement accuracy
（
average value sampling
mode
）
The voltage difference (△
V) between any two points on the
waveform after averaging the captured waveforms more than 16:
±
(5% reading + 0.05 divisions).
Trigger
Triggering level range
±6 divisions from the screen center
Triggering level accuracy (typical)
which is applicable to the signal
with rise and fall time equal to or
longer than 20ns
±0.3 divisions
Trigger displacement
655 divisions for pre-triggering and 4 divisions for post-
triggering.
Trigger Holdoff range 100 ns – 10 s
Make a 50% level setting
(Typical).
Operation with the input signal frequency equal to or larger
than 50Hz.
