multicomp pro HDS-N Series User Manual

10-Appendix
76
10. Appendix
10.1 Appendix A: Specifications
10.1.1 Oscilloscope
Only if other instructions are provided, are all technical specifications applicable to the probe with
the 10X attenuation switch setting and the HDS-N series digital type oscilloscope. In order to be
up to these specifications, the oscilloscope should meet the following requirement.
■ The instrument should operate continuously for more than 30 minutes under the specified
operating temperature.
■ If the operating temperature is up to or larger than 5 Celsius degrees, the system function
menu must be opened to make the system perform a "Auto- calibration" procedure (see
"calibration" on P54).
Except those specifications marked with the word Typical, all specifications can be up to.
Sampling
Sampling modes
Normal sampling
Peak detection
Average value
Sampling rate
MP720014
Max 500 MS/s
MP720015
Max 500 MS/s
Input
Input coupling
DC, AC, Ground
Input impedance
1 MΩ±2% connected in parallel with 20 pF±5 pF
Probe attenuation coefficient 1X, 10X, 100X, 1000X
Max. Input voltage 400 V (peak)
Channel delay time（typical）
150 ps
Horizontal
Sampling rate range
MP720014
0.25 S/s - 500 MS/s
MP720015 0.25 S/s - 500 MS/s
Waveform interpolation
（
sin x
）
/x
Record length 6k points on each channel
Scanning speed range
（S/div）
5ns/div - 100s/div, stepping in the "1-2-5" mode
