10-Appendix
79
Voltage (VAC)
Input Impedance: 10 MΩ
Max Input Voltage: 750 V (AC, RMS value)
Frequency range: from 40 Hz to 400 Hz
Display: RMS value of the sine wave
Range Accuracy Resolution
4.000 V
±1%±3 digits
1 mV
40.00 V
10 mV
400.0 V
100 mV
750 V
±1.5%±3 digits
1 V
Direct Current (DC)
Range Accuracy Resolution
40.00 mA
±1.5%±1 digit
10 uA
400.0 mA
±1.5%±1 digit
100 uA
10 A
±3%±3 digits
10 mA
Alternating Current (AC)
Range Accuracy Resolution
40.00 mA
±1.5%±3 digits
10 uA
400.0 mA
±
2%
±
3 digits
100 uA
10 A
±
5%
±
3digits
10 mA
Resistance
Range Accuracy Resolution
400.0 Ω
±1%±3 digits
0.1 Ω
4.000 kΩ 1 Ω
40.00 kΩ
10 Ω
400.0 kΩ
100 Ω
4.000 MΩ 1 kΩ
40.00 MΩ
±1.5%±3 digits
10 kΩ
Capacitance
Range
Accuracy
Resolution
51.20 nF
±3%±3 digits
10 pF
512.0 nF 100 pF
5.120 uF 1 nF
51.20 uF 10 nF
100 uF 100 nF
Diode: Voltage reading: 0 V - 1 V.
On-off Test: There is a beep sound when the on-resistance is less than 50 Ω.
