COCKPIT SX M-LINK
MULTIPLEX Modellsport GmbH & Co.KG • Westliche Gewerbestraße 1 • D-75015 Bretten (Gölshausen) • www.multiplex-rc.de Page 28
! Caution:
If you make a change to the F-RESP setting, you will
need to repeat the binding procedure (Î 10.2.).
20. Trainer mode operations
20.2. The COCKPIT SX M-LINK
as Pupil transmitter
If used as a Pupil transmitter, the COCKPIT SX M-LINK
can be connected to the following MULTIPLEX Teacher
transmitters:
C
OCKPIT SX, COCKPIT SX M-LINK
PROFI mc 4000, PROFI mc 3010 / 3030
ROYALevo/pro 7/9/12
ROYALpro 7/9/16 M-LINK
(see the Internet for a table of other types)
If you wish to use the C
OCKPIT SX M-LINK as a Pupil
transmitter, follow this procedure:
1. Switch both transmitters
off.
2. Insert the plug marked Schüler (pupil) into the
multi-function socket of the C
OCKPIT SX M-LINK.
Insert the plug marked Lehrer (teacher) into the
multi-function socket of the Teacher transmitter.
3. Switch on the Teacher transmitter only
!
Power is fed to the C
OCKPIT SX M-LINK via the
Trainer lead.
PUPILU flashes on the screen.
4. Use the 3-D digi-adjuster to select the pupil type
PUPILM for use with the following MULTIPLEX
transmitters:
e.g. PROFI mc 3010/3030/4000
! Note: ROYALevo/pro as Teacher transmitter
If you use a ROYALevo/pro 7/9/12 or a ROYALpro
7/9/16 M-LINK as Teacher transmitter, the selected
Teacher type on the ROYALevo/pro must be the
same as the Pupil type on the C
OCKPIT SX M-LINK:
ROYALevo/pro
COCKPIT SX M-LINK
Teach.M Î PUPILM
Teach.U Î PUPILU
ROYALpro M-LINK
COCKPIT SX M-LINK
Teach.U Î PUPILU
5. A brief button press (r) stores the setting permanent-
ly. For safety’s sake it is now no longer possible to
change the transmitter’s setting.
If you wish to terminate Pupil mode, you must switch
the Teacher transmitter off and disconnect the
Trainer lead.
21. Accessories and spare parts
Item Order No.
2.4 GHz transmitter aerial
# 89 3007
Aluminium stick-tops (1 pair)
# 7 5304
6-cell NiMH transm. battery, 1800 mAh
# 15 6001
Transmitter charge lead (diode plug)
# 8 6020
Transmitter case
# 76 3323
Transmitter tray
# 8 5306
PROFI transmitter neckstrap
# 8 5646
Padded cushion for PROFI neckstrap
# 8 5641
“Cross-over” transmitter support strap
# 8 5640
USB simulator interface lead
# 8 5153
USB PC lead for transmitter
(data back-up / update)
# 8 5148
Trainer lead (straight connectors)
Trainer lead (right-angled connectors)
(Î 20.)
# 8 5121
# 8 5118
Plug-type battery charger,
230 V / 50 Hz / 2 x 150 mA
# 145537
For more information relating to accessories and
replacement parts please consult the current main
catalogue or our Internet website: www.multiplex-rc.de.
22. Multi-function socket interfaces
The multi-function socket of the COCKPIT SX M-LINK
provides the following functions:
x Charge / discharge the transmitter battery Î 8.
x Trainer mode operations Î 20., Î 20.2.
x PC socket for flight simulator Î 22.1.
x PC socket for data back-up / update Î 22.2.
22.1. PC socket for flight simulator
The Cockpit SX M-LINK can be used directly and with-
out further modification as a control unit for many flight
simulators. Special interface leads for MULTIPLEX
transmitters are available from flight simulator manu-
facturers.
If you have queries, please consult the manufacturer of
your simulator program.
Free model flight simulator (FMS) on the MULTI-
PLEX website:
The USB interface lead for use with this simulator is
available from model shops under Order No. (# 8 5153).
