Hardware Installation 2-55
Connecting ACPower
Caution: Do not connect or disconnect the Power Cable from the terminal with the
AC Power Cord connected to an AC outlet. It is recommended to disconnect the AC
Power Cord from the AC outlet and wait 30 seconds before connecting or disconnecting
the Power Supply cable from the terminal.
The CX5 receives power from an external 24V power brick.
Caution: The CX5 requires the NCR 24V power supply that is shipped with the
terminal. Use of other power bricks may cause damage to the unit.
1. Connect the Power Supply cable to the Power In connector on the Base.
2. Connect the AC Power Cord to the Power Supply and to an AC outlet.
