1-20 Product Overview
LAN
The Motherboard provides 10/100/Gb LAN support using Intel I210.
Signal Name Pin Pin Signal Name
MDIP0 1 2 MDIN0
MDIP1 3 4 MDIN1
MDIP2 5 6 MDIN2
MDIP3 7 8 MDIN3
The LAN connector features an Activity, Link, and Speed indicator LED. For more
information, refer to LAN Diagnostic LEDs on page77.
