NCR CX5 User Manual

1-2 Product Overview
I/O Board Connectors
USBCentric I/O
(Retail)
Serial Centric I/O
(Hospitality)
Cash Drawer (12/24 V) 1 (dual port) 2
LAN 1 1
Both I/O boards are connected to the CX5 core motherboard through a single USB Type-
C connector. In addition to the integration of the board in the base, each I/O can be
configured for a wall mount solution, pole mount solution, or ordered in a remote
chassis to permit placement under the counter.
Base Models
Model Description
7773-1215-8801 CX5, 15" 4:3 PCAP, 4GB DDR3L memory, No HDD, No
Power Supply
7773-1216-8801 CX5, 15.6" PCAP, 4GB DDR3L memory, No HDD, No Power
Supply

NCR CX5 Specifications

General

Memory	4GB DDR3
Touch Technology	Projected Capacitive
Operating System	Windows 10 IoT
Ports	Ethernet
Weight	5.5 kg
