NCR CX5 - Serial Centric I;O (Hospitality); Base

1-26 Product Overview
Serial Centric I/O(Hospitality)
Base
The following are the default I/O ports for the NCR CX5 All-in-One POS (7773) with a
Serial Centric I/O(Hospitality)Base.
Callout Port Name
1 RJ45 Serial
• COM5 (Enhanced UART)
• COM6 (Standard UART)
2 Dual USB 3.0
3 USB12V
4 USB24V
5 24VPower In
6 Status LED
7 USB-C
8 LANOut
Note: Connect to the CXHead
9 LAN In
Note: Connect to Ethernet Network
10 DisplayPort
11 Cash Drawer B
