Page 70 of 121
Status
The Status page contains 5 menus:
o
Switch Statistics
o Port Statistics
o Port Settings
o MAC Address Table
o Error Chart
Status > Switch Statistics
The Switch Statistics Chart allows you to compare one type of statistic across all the ports.
Switch Statistics Chart
o
Statistics The type of system data to be monitored
o
Refresh Rate The time interval between automatic refreshes (5, 10, 15, 30 seconds)
o
Color The color setting for the chart
There are 24 kinds of Statistics that you can review on this screen:
Inbound Octet Rate: Received Byte per second.
Inbound Unicast Packet Rate: Received Unicast packet per second.
Inbound Non-unicast Packet rate: Received Non-unicast packet per second.
Inbound Discard Rate: Received and is discarded packet per second.
Inbound Error Rate: Received error packet per second.
Outbound Octet Rate: Transmitted byte per second.
Outbound Unicast Packet Rate: Transmitted unicast packet per second.
Outbound Non-unicast Packet rate: Transmitted non-unicast packet per second.
Outbound Discard Rate: Transmitted and is discarded packet per second.
Outbound Error Rate: Transmitted error packet per second.
Ethernet Undersize Packet Rate: Less than 64byte length packet per second.
Ethernet Oversize Packet Rate: More than 1518byte length packet per second
Inbound Octets: Received bytes
Inbound Unicast Packets: Received unicast packet
Inbound Non-unicast Packets: Received non-unicast packet
Inbound Discards: Received and is being discarded packet.
Inbound Errors: Received and is a error packet
Outbound Octets: Transmitted byte
Outbound Unicast Packets: Transmitted unicast packet
Outbound Non-unicast Packets: Transmitted non-unicast packet.
Outbound Discards: Transmitted and is being discarded packet
Outbound Errors: Transmitted and is an Error packet.
Ethernet Undersize Packets: Less than 64byte length packet
Ethernet Oversize Packets: more than 1518 byte length packet.
