NETGEAR WAC104 User Manual

Table 2. WAC104 AP factory default settings (Continued)
Default SettingFeature
2346Fragmentation length
2347CTS/RTS threshold
Long PreamblePreamble mode
Automatic, nonconfigurable
Note: Throughput can vary. Network conditions and environmental
factors, including volume of network traffic, building materials and
construction, and network overhead, affect the data throughput rate.
Transmission speed
100%, nonconfigurableRadio transmission power
Enabled, nonconfigurable802.11e WMM
WPS
EnabledWPS capability
Enabled. For more information, see Manage the WPS settings on page
73.
AP’s PIN
EnabledKeep Existing Wireless
Settings
Technical specifications
The following table shows the technical specifications of the AP.
Table 3. WAC104 AP specifications
DescriptionFeature
12V, 1.5A (18W)
The plug is localized to the country of sale.
Power consumption 8.1W maximum
Power adapter
9.43 x 7.16 x 1.61 in. (239.65 x 181.45 x 40.6 mm)Dimensions (L x W x H)
0.85 lb (385 g )Weight
32º to 104ºF (0° to 40°C)Operating temperature
10 to 90% maximum relative humidity, noncondensingOperating humidity
–20º to 70ºF (–4° to 158°C)Storage temperature
5 to 95% maximum relative humidity, noncondensingStorage humidity
User Manual93Factory Default Settings and
Technical Specifications
802.11ac Wireless Access Point Model WAC104

NETGEAR WAC104 Specifications

General

Ethernet WAN	-
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
Number of WLAN connections (max)	128
WLAN data transfer rate (first band)	300 Mbit/s
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Antennas quantity	3
Security algorithms	WEP, WPA-PSK, WPA2-PSK
Power source type	AC
Power consumption (typical)	8.1 W
Product type	Tabletop router
Product color	Black
LED indicators	LAN, WPS
USB port	No
Ethernet LAN (RJ-45) ports	4
Storage temperature (T-T)	-120 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	CE (EN60950)
Mean time between failures (MTBF)	285000 h
Cables included	LAN (RJ-45)
Package depth	192 mm
Package width	247 mm
Package height	98 mm
Package weight	780 g
Harmonized System (HS) code	85176990
Shipping (inner) case width	507 mm
Shipping (inner) case height	270 mm
Shipping (inner) case length	399 mm
Shipping (inner) case net weight	8620 g
Number of layers per pallet (sea)	7 pc(s)
Number of cartons per pallet layer	5 pc(s)
Quantity per shipping (inner) case	10 pc(s)

Weight and Dimensions

Depth	181.45 mm
Width	239.65 mm
Height	40.6 mm
Weight	385 g
