NETGEAR WNDAP360 User Manual

Installation and Basic Configuration
25
ProSafe Dual Band Wireless-N Access Point WNDAP360
5. Specify the remaining wireless settings as explained the following table:
Table 6. Basic 2.4-GHz Band Wireless Settings
Field Descriptions
Wireless Network Name
(SSID)
Enter a 32-character (maximum) service set identifier (SSID); the characters are
case-sensitive. The default is NETGEAR_11ng. The SSID assigned to a wireless
device needs to match the wireless access point’s SSID for the wireless device
to communicate with the wireless access point. If the SSIDs do not match, you
will not get a wireless connection to the wireless access point.
Scheduler Status This is a nonconfigurable field that show th
e status of the wireless scheduler. For
more information, see Schedule the Wireless Radio to Be Turned Off on
page 55.
Broadcast Wireless
Network Name (SSID)
Select the Ye
s radio button to enable the wireless access point to broadcasts its
SSID, allowing wireless stations that have a null (blank) SSID to adopt the
wireless access point’s SSID. Yes is the default setting. To prevent the SSID
from being broadcast, select the No radio button.
Channel / Frequency From the drop-down list, select the channel you wish to use on your wireless
LAN. The
wireless channels and frequencies depend on the country and
wireless mode. The default setting is Auto.
Note: It should not be necessary to change the wireless channel unless you
expe
rience interference (indicated by lost connections or slow data transfers).
Should this happen, you might want to experiment with different channels to see
which is the best. For more information, see Operating Frequency (Channel)
Guidelines on
page 29.
Note: For more information about available channels and frequencies, see
Technical Specifications in Appendix A.
11ng mode only
Note: For most
networks, the
default
settings will work fine.
MCS Index / Data
Rate
From the drop-down list, select a Modulation and Coding
Scheme (MCS) in
dex and transmit data rate for the wireless
network. The default setting is Best. For a list of all options
that you can select from in 11ng mode, see Factory Default
Settings in Appendix A.
Channel Width From the drop-down list, select a channel width. The options
are Dynami
c 20/40 MHz, 20 MHz, or 40 MHz. A wider
channel improves the performance, but some legacy devices
can operate only in either 20 MHz or 40 MHz.
Ext Protection
Sp
acing
When you select a channel width of Dynamic 20/40 MHz or
40 MHz, you also need to select protection spacing for the
extension channel from the Ext Protection Spacing
drop-down list. In addition to the default value Auto, you can
also select a value of 20 or 25.
Note: This field is not applicable when the channel width is
set
to 20 MHz.

NETGEAR WNDAP360 Specifications

General

VLAN support	Yes
Frequency band	2.4 - 5 GHz
Number of users	50 user(s)
Cabling technology	10/100/1000BASE-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Antenna connector type	SMA
Antenna gain level (max)	5 dBi
Weight (imperial)	1.93 lbs
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE802.1x
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, EAP, EAP-TLS, EAP-TTLS, PEAP, SSH, SSL/TLS, TTLS, WEP, WPA, WPA2
Power requirements	12 VDC, 1A
Power consumption (typical)	10.51 W
Minimum system requirements	Internet Explorer 6.0, Mozilla Firefox 1.5
Compatible operating systems	- Windows Vista, XP, 2000, 98, Me - Mac OS - UNIX - Linux
Internal	No
LED indicators	LAN
Cable lock slot type	Kensington

Weight and Dimensions

Height	54.76 mm
Weight	878 g
Dimensions (WxDxH)	253.75 x 253.76 x 54.76 mm
