NETGEAR WNDAP360 User Manual

Installation and Basic Configuration
16
ProSafe Dual Band Wireless-N Access Point WNDAP360
In order for this to work correctly, verify that you have met all of the system requirements,
shown in System Requirements on p
age 7.
Install and configure your wireless access point in
the order of the following sections:
1. Connect the Wireless Access Point to Computer
2. Log In to the Wireless Access Point
3. Configure Basic General System Settings
and Time Settings
4. Configure IP Settings and Optional DHCP Server Settings
5. Configure Basic Wireless Settings
Connect the Wireless Access Point to Computer
Tip: Before you place the wireless access point in an elevated position that is
difficult to reach, first set up and test the wireless access point to verify
wireless network connectivity.
 To set up the wireless access point:
1. Unp
ack the box and verify the contents.
2. Prep
are a computer with an Ethernet adapter. If this computer is already part of your
network, record its TCP/IP configuration settings. Configure the computer with a static IP
address of 192.168.0.210 and 255.255.255.0 as the subnet mask.
3. Connect an Ethern
et cable from the wireless access point to the computer (point A in the
following figure).
4. Securely insert
the other end of the cable into the wireless access point’s Ethernet port
(point B in the following figure).
.
Figure 4.
A
B
Ethernet cable
Ethernet port
WNDAP360

NETGEAR WNDAP360 Specifications

General

VLAN support	Yes
Frequency band	2.4 - 5 GHz
Number of users	50 user(s)
Cabling technology	10/100/1000BASE-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Antenna connector type	SMA
Antenna gain level (max)	5 dBi
Weight (imperial)	1.93 lbs
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE802.1x
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, EAP, EAP-TLS, EAP-TTLS, PEAP, SSH, SSL/TLS, TTLS, WEP, WPA, WPA2
Power requirements	12 VDC, 1A
Power consumption (typical)	10.51 W
Minimum system requirements	Internet Explorer 6.0, Mozilla Firefox 1.5
Compatible operating systems	- Windows Vista, XP, 2000, 98, Me - Mac OS - UNIX - Linux
Internal	No
LED indicators	LAN
Cable lock slot type	Kensington

Weight and Dimensions

Height	54.76 mm
Weight	878 g
Dimensions (WxDxH)	253.75 x 253.76 x 54.76 mm
