NETGEAR WNDAP360 User Manual

Advanced Configuration
98
ProSafe Dual Band Wireless-N Access Point WNDAP360
Note: You can extend this multipoint bridging configuration by adding
additional wireless access points that are configured in point-to-point
mode for each additional LAN segment. Furthermore, you can
extend the range of the wireless network with NETGEAR wireless
antenna accessories.
Configure the Wireless Access Point to Repeat the Wireless
Signal Using Point-to-Multipoint Bridge Mode
You can configure the wireless access point to repeat the wireless signal, without
communication with other wireless clients. All traffic is sent to the remote or downstream
wireless access point. You can configure up to four security profiles to enable the wireless
access point to repeat the wireless signal for four remote wireless access points. Each
security profile requires a unique name and needs to include the MAC address of the remote
wireless access point. You can configure up to four such security profiles
(NETGEAR-WDS-1, NETGEAR-WDS-2, and so on).
The following figure shows an example in
which AP1, AP2, and AP3 repeat the wireless
signal in point-to-multipoint bridge mode. AP2 requires a security profile for AP1 and another
one for AP3:
Figure 59.
Multipoint
Router
Hub or switch
bridge mode
repeating only
Multipoint
bridge mode
repeating only
Multipoint
bridge mode
repeating only

NETGEAR WNDAP360 Specifications

General

VLAN support	Yes
Frequency band	2.4 - 5 GHz
Number of users	50 user(s)
Cabling technology	10/100/1000BASE-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Antenna connector type	SMA
Antenna gain level (max)	5 dBi
Weight (imperial)	1.93 lbs
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE802.1x
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, EAP, EAP-TLS, EAP-TTLS, PEAP, SSH, SSL/TLS, TTLS, WEP, WPA, WPA2
Power requirements	12 VDC, 1A
Power consumption (typical)	10.51 W
Minimum system requirements	Internet Explorer 6.0, Mozilla Firefox 1.5
Compatible operating systems	- Windows Vista, XP, 2000, 98, Me - Mac OS - UNIX - Linux
Internal	No
LED indicators	LAN
Cable lock slot type	Kensington

Weight and Dimensions

Height	54.76 mm
Weight	878 g
Dimensions (WxDxH)	253.75 x 253.76 x 54.76 mm
