NETGEAR WNDAP360 User Manual

Advanced Configuration
86
ProSafe Dual Band Wireless-N Access Point WNDAP360
4. Click Apply to save your settings.
Configure Advanced QoS Settings
For most networks, the default Quality of Service (QoS) queue settings work well. For
information about how to configure basic QoS, see Configure Basic Wireless Quality of
Service o
n page 56.
You can specify the settings on multiple queues for increased throughput and better
perfo
rmance of differentiated wireless traffic such as Voice-over-IP (VoIP), other types of
audio, video, and streaming media, as well as traditional IP data.
The advanced QoS options on the wireless access point are as follows:
• AP EDC
A parameters. Specify the access point (AP) Enhanced Distributed Channel
Access (EDCA) settings for different types of data transmitted from the wireless access
point to wireless clients.
• S
tation EDCA parameters. Specify the station EDCA parameters for different types of
data transmitted from the wireless clients to the wireless access point. If WMM is
disabled, you cannot configure the Station EDCA parameters. (For information about how
to enable WMM, see Configure Basic Wireless Quality of Service on p
age 56.)
Preamble Type
Note: This setting does not apply
to th
e 802.11a/na modes.
Select one of the following radio buttons to specify the preamble type:
• Lon
g. A long transmit preamble might provide a more reliable
connection or a slightly longer range. A short transmit preamble
gives better performance.
• Auto. The
Auto settings automatically handles both long and short
preambles. The default setting is Auto.
Antenna
Note: This setting does not apply
to th
e 802.11a/na modes.
Select one of the following radio buttons to specify the antenna:
• Internal. Enables the internal antenna. This is the default setting.
• External.
Enables an optional external antenna.
802.11d
Note: This setting does not apply
to th
e 802.11a/na modes.
Select this check box to enable support for additional regulatory
domain
s that are not in the current standard; support includes the
addition of a country information element to beacons, probe requests,
and probe responses. This check box is selected by default.
Client Isolation From the drop-down list, select one of the following options:
• Enable. Commun
ication between wireless clients that are associated
to different virtual access points (VAPs) is blocked.
• Di
sable. Communication between wireless clients that are
associated to different VAPs is allowed. This is the default setting.
Max. Wireless Clients Enter the maximum number of wireless clients that can simultaneously
co
nnect to the wireless access point at one time. The default setting is
64 clients.
Table 24. Advanced Wireless Settings (Continued)
Field Description

NETGEAR WNDAP360 Specifications

General

VLAN support	Yes
Frequency band	2.4 - 5 GHz
Number of users	50 user(s)
Cabling technology	10/100/1000BASE-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Antenna connector type	SMA
Antenna gain level (max)	5 dBi
Weight (imperial)	1.93 lbs
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE802.1x
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, EAP, EAP-TLS, EAP-TTLS, PEAP, SSH, SSL/TLS, TTLS, WEP, WPA, WPA2
Power requirements	12 VDC, 1A
Power consumption (typical)	10.51 W
Minimum system requirements	Internet Explorer 6.0, Mozilla Firefox 1.5
Compatible operating systems	- Windows Vista, XP, 2000, 98, Me - Mac OS - UNIX - Linux
Internal	No
LED indicators	LAN
Cable lock slot type	Kensington

Weight and Dimensions

Height	54.76 mm
Weight	878 g
Dimensions (WxDxH)	253.75 x 253.76 x 54.76 mm
