NETGEAR WNDAP360 User Manual

81
5
5. Advanced Configuration
This chapter describes how to configure the advanced features of your ProSafe Dual Band
Wireless-N Access Point WNDAP360. This chapter includes the following sections:
• Spanning Tree Protocol and 802.1Q VLAN
• Hotspot Settings
• Configure Advanced Wireless Settings
• Configure Advanced QoS Settings
• Configure Wireless Bridging
Spanning Tree Protocol and 802.1Q VLAN
The advanced General system settings screen allows you to enable the Spanning Tree
Protocol (STP) and configure the VLANs.
STP provides network traffic optimization in locations wh
ere multiple wireless access points
are active.
The 802.1Q VLAN protocol on the wireless access point logically separates traffic on the
sam
e physical network:
• Unt
agged VLAN. When the wireless access point sends frames that are associated with
the untagged VLAN from its Ethernet interface, those frames are untagged. When the
wireless access point receives untagged frames over its Ethernet interface, those frames
are assigned to the untagged VLAN.
Note: Select the Untagged VLAN check box only if the hubs and switches
on your LAN support the 802.1Q VLAN protocol. Likewise, change
the untagged VLAN value only if the hubs and switches on your LAN
support the 802.1Q VLAN protocol. Selecting the Untagged VLAN
check box or changing the untagged VLAN value will result in a loss
of IP connectivity if the hubs and switches on your LAN have not yet
been configured with the corresponding VLAN.

NETGEAR WNDAP360 Specifications

General

VLAN support	Yes
Frequency band	2.4 - 5 GHz
Number of users	50 user(s)
Cabling technology	10/100/1000BASE-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Antenna connector type	SMA
Antenna gain level (max)	5 dBi
Weight (imperial)	1.93 lbs
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE802.1x
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, EAP, EAP-TLS, EAP-TTLS, PEAP, SSH, SSL/TLS, TTLS, WEP, WPA, WPA2
Power requirements	12 VDC, 1A
Power consumption (typical)	10.51 W
Minimum system requirements	Internet Explorer 6.0, Mozilla Firefox 1.5
Compatible operating systems	- Windows Vista, XP, 2000, 98, Me - Mac OS - UNIX - Linux
Internal	No
LED indicators	LAN
Cable lock slot type	Kensington

Weight and Dimensions

Height	54.76 mm
Weight	878 g
Dimensions (WxDxH)	253.75 x 253.76 x 54.76 mm
