NETGEAR WNDAP360 User Manual

Wireless Configuration and Security
51
ProSafe Dual Band Wireless-N Access Point WNDAP360
Configure RADIUS Server Settings
For authentication, accounting, or both authentication and accounting using RADIUS, you
need to configure primary servers and optional secondary servers. These RADIUS server
settings can apply to all devices that are connected to the wireless access point.
 To configure the RADIUS server settings:
1. Select Config
uration > Security > Advanced > Radius Server Settings. The Radius
Server Settings screen displays. (The following figure shows some examples.)
Table 13. WPA-PSK, WPA2-PSK, and WPA-PSK & WPA2-PSK Settings
Field Descriptions
Data Encryption TKIP Temporal Key Integrity Protocol (TKIP) is th
e standard encryption method
used with WPA. You can also use TKIP with WPA2.
Note: TKIP provides only legacy (slower) rates of operation. NETGEAR
recommends
WPA2 authentication with AES encryption if you want to use the
11n rates and speed.
AES Advanced Encryption Standard (AES) is the st
andard encryption method used
with WPA2.
Note: Although some wireless clients might support AES with WPA, the
WNDAP360 wireless
access point does not support WPA with AES.
TKIP + AES TKIP + AES supports both WPA and WPA2. Broadcast packets use TKIP. For
unicast (point-to-point) transmissions, WPA clients use TKIP, and WPA2
clients use AES.
For the WPA & WPA2 mixed mode, TKIP
+ AES is the only supported data
encryption method.
Passphrase Enter a passphrase. The passphrase length needs to be between 8 and 63 characters
(inclusive). The default passphrase is sharedsecret.
You can display the actual passphrase by selecting the Sho
w Passphrase in Clear Text
radio button.
Show Passphrase
in Clea
r Text
Select the Yes radio button to display the actual passphrase in the Passphrase field. The
default setting is No.

NETGEAR WNDAP360 Specifications

General

VLAN support	Yes
Frequency band	2.4 - 5 GHz
Number of users	50 user(s)
Cabling technology	10/100/1000BASE-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Antenna connector type	SMA
Antenna gain level (max)	5 dBi
Weight (imperial)	1.93 lbs
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE802.1x
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, EAP, EAP-TLS, EAP-TTLS, PEAP, SSH, SSL/TLS, TTLS, WEP, WPA, WPA2
Power requirements	12 VDC, 1A
Power consumption (typical)	10.51 W
Minimum system requirements	Internet Explorer 6.0, Mozilla Firefox 1.5
Compatible operating systems	- Windows Vista, XP, 2000, 98, Me - Mac OS - UNIX - Linux
Internal	No
LED indicators	LAN
Cable lock slot type	Kensington

Weight and Dimensions

Height	54.76 mm
Weight	878 g
Dimensions (WxDxH)	253.75 x 253.76 x 54.76 mm
