NETGEAR WNDAP360 User Manual

Advanced Configuration
97
ProSafe Dual Band Wireless-N Access Point WNDAP360
g. Click Apply to save your security profile settings. The Bridging screen displays
again.
h. Rep
eat step b through step g for any other security profile that you want to edit.
For example, first configure security profile NETGEAR-WDS-1 with the
MAC address
of AP2, and then configure security profile NETGEAR-WDS-2 with the MAC address
of AP3 (see Figure 56 on p
age 94).
3. Activate the wireless access
point (AP1 on LAN Segment 1 in Figure 56 on page 94) as
a point-to-multipoint bridge (that is, it is the master in the wireless network):
a. On th
e Bridging screen, select the Enable Wireless Bridging check box.
b. Select
the Wireless Point-to-Multi-Point Bridge radio button.
c. Select the Ena
ble Wireless Client Association check box to enable wireless client
association.
Note: If you do not select the Enable Wireless Client Association check
box, the wireless access point will not function in point-to-multipoint
bridge but in repeater mode.
d. If the correct profile names and security options are displayed in the table, select the
check boxes in the Enable column for all security profiles that you want to enable.
e. Click Apply in th
e Bridging screen to activate your point-to-multipoint bridge
settings.
4. Conf
igure AP2 on LAN Segment 2 (see Figure 56 on page 94) in point-to-point bridge mode
with the remote MAC address of AP1.
5. Conf
igure AP3 on LAN Segment 3 (see Figure 56 on page 94) in point-to-point bridge mode
with the remote MAC address of AP1.
6. V
erify the following for all wireless access points:
• On
ly AP1 on LAN Segment 1 is configured in point-to-multipoint bridge mode, and all
others APs are configured in point-to-point bridge mode.
• AP2 and
AP3 (the point-to-point APs) needs to have AP1’s MAC address in their
Remote MAC Address field.
• All
APs need to be on the same LAN, that is, the LAN IP addresses of all APs need to
be in the same network as the LAN devices.
• If you use DHCP
, all wireless access points need to obtain an IP address
automatically (as a DHCP client). For more information, see Configure IP Settings
and Optional DHCP Server Settings on p
age 21.
• All wireless a
ccess points need to use the same channel, authentication mode, and
security settings.
7. V
erify connectivity across the LANs:
• A compute
r on any LAN segment should be able to connect to the Internet or share
files and printers with any other PCs or servers connected to any of the three LAN
segments.

NETGEAR WNDAP360 Specifications

General

VLAN support	Yes
Frequency band	2.4 - 5 GHz
Number of users	50 user(s)
Cabling technology	10/100/1000BASE-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Antenna connector type	SMA
Antenna gain level (max)	5 dBi
Weight (imperial)	1.93 lbs
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE802.1x
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, EAP, EAP-TLS, EAP-TTLS, PEAP, SSH, SSL/TLS, TTLS, WEP, WPA, WPA2
Power requirements	12 VDC, 1A
Power consumption (typical)	10.51 W
Minimum system requirements	Internet Explorer 6.0, Mozilla Firefox 1.5
Compatible operating systems	- Windows Vista, XP, 2000, 98, Me - Mac OS - UNIX - Linux
Internal	No
LED indicators	LAN
Cable lock slot type	Kensington

Weight and Dimensions

Height	54.76 mm
Weight	878 g
Dimensions (WxDxH)	253.75 x 253.76 x 54.76 mm
