NETGEAR WNDAP360 User Manual

Advanced Configuration
96
ProSafe Dual Band Wireless-N Access Point WNDAP360
Authentication Settings
Network Authentication
and
Data Encryption
From the Network Authentication drop-down list, select Open System,
WPA-PSK, or WPA2-PSK. Your selection determines the options that the
Data Encryption drop-down list provides, and whether or not the WPA
Passphrase (Network Key) field displays.
Open System Although you can use the bridge co
mmunication without any
authentication and encryption, NETGEAR recommends that
you use WEP if you do select an open system. From the
Data Encryption drop-down list, select one of the following:
• None. No
authentication and encryption.
• 64-b
it WEP. Standard WEP encryption, using 40/64-bit
encryption.
• 12
8-bit WEP. Standard WEP encryption, using 104/128-bit
encryption.
• 152
-bit WEP. Proprietary WEP encryption mode, using
128+24 bits encryption. This mode functions only with
other wireless station that support this mode.
WPA-PSK TKIP (T
emporal Key Integrity Protocol) is the standard
encryption method used with WPA-PSK and the only
selection possible from the Data Encryption drop-down list.
In the WPA Passphrase (Network Key) field, enter a
p
assphrase. The passphrase length needs to be between
8 and 63 characters (inclusive).
WPA2-PSK AES (Adva
nced Encryption Standard) is the standard
encryption method used with WPA2-PSK and the only
selection possible from the Data Encryption drop-down list.
In the WPA Passphrase (Network Key) field, enter a
p
assphrase. The passphrase length needs to be between
8 and 63 characters (inclusive).
Note: NETGEAR recommends WPA2-PSK authentication
with AES en
cryption if you want to use the 11n rates and
speed.
Link Test
IP Address To verify the connection between the access point and the wireless station
that you inten
d to build a bridge with, enter the IP address of the wireless
station, and then click Link Test. The Link Test Process Status field displays
the results of the test (Uninitialized, In Process, Success, Timed Out, or
Failure).
Note: You should be able to ping the IP address of both APs from a
con
nected client. Failure to ping one of the APs means that the wireless signal
is not traversing the bridge. Failure to ping both IP addresses means that the
clients is not connected correctly.
Table 27. Point-to-Multipoint Bridge Profile and Authentication Settings (Continued)
Field Description

NETGEAR WNDAP360 Specifications

General

VLAN support	Yes
Frequency band	2.4 - 5 GHz
Number of users	50 user(s)
Cabling technology	10/100/1000BASE-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Antenna connector type	SMA
Antenna gain level (max)	5 dBi
Weight (imperial)	1.93 lbs
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE802.1x
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, EAP, EAP-TLS, EAP-TTLS, PEAP, SSH, SSL/TLS, TTLS, WEP, WPA, WPA2
Power requirements	12 VDC, 1A
Power consumption (typical)	10.51 W
Minimum system requirements	Internet Explorer 6.0, Mozilla Firefox 1.5
Compatible operating systems	- Windows Vista, XP, 2000, 98, Me - Mac OS - UNIX - Linux
Internal	No
LED indicators	LAN
Cable lock slot type	Kensington

Weight and Dimensions

Height	54.76 mm
Weight	878 g
Dimensions (WxDxH)	253.75 x 253.76 x 54.76 mm
