NETGEAR WNDAP360 User Manual

Installation and Basic Configuration
27
ProSafe Dual Band Wireless-N Access Point WNDAP360
Configure 802.11a/na Wireless Settings
 To configure the 802.11a/na wireless settings:
1. Select Con
figuration > Wireless > Basic > Wireless Settings. The basic Wireless
Settings screen displays. (The following figure shows the 802.11na settings.)
Figure 13.
2. Specify the wireless mode in the 5-GHz band by selecting one of the following radio buttons:
• 11
a. 802.11n-compliant devices can connect to the access point because they are
backward compatible.
• 1
1na. This is the default setting. If you keep the default setting, go to step 5.
When you change the wireless mode, the Turn Radio On check box is automatically
cle
ared, and all fields, button, and drop-down list onscreen are masked out.
3. T
urn on the radio by selecting the Turn Radio On check box. A popup screen displays.
Note: Under normal conditions you want the radio to be turned on. Turning off
t
he radio disables access through the wireless access point, which can be
helpful for configuration, network tuning, or troubleshooting activities.
4. Click OK
to confirm the change of wireless mode. The change does not take effect until you
click the Apply button after you have completed the wireless configuration.

NETGEAR WNDAP360 Specifications

General

VLAN support	Yes
Frequency band	2.4 - 5 GHz
Number of users	50 user(s)
Cabling technology	10/100/1000BASE-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Antenna connector type	SMA
Antenna gain level (max)	5 dBi
Weight (imperial)	1.93 lbs
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE802.1x
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, EAP, EAP-TLS, EAP-TTLS, PEAP, SSH, SSL/TLS, TTLS, WEP, WPA, WPA2
Power requirements	12 VDC, 1A
Power consumption (typical)	10.51 W
Minimum system requirements	Internet Explorer 6.0, Mozilla Firefox 1.5
Compatible operating systems	- Windows Vista, XP, 2000, 98, Me - Mac OS - UNIX - Linux
Internal	No
LED indicators	LAN
Cable lock slot type	Kensington

Weight and Dimensions

Height	54.76 mm
Weight	878 g
Dimensions (WxDxH)	253.75 x 253.76 x 54.76 mm
