NETGEAR WNDAP360 User Manual

Wireless Configuration and Security
48
ProSafe Dual Band Wireless-N Access Point WNDAP360
Configure Legacy 802.1X
To use legacy 802.1X security, you need to define RADIUS server settings. For information
about RADIUS servers, see Configure RADIUS Server Settings on p
age 51.
When you select Le
gacy 802.1X from the Network Authentication drop-down list, the Data
Encryption drop-down list becomes nonoperational (it shows None only). You need to define
the RADIUS servers only to use legacy 802.1X security.
Figure 20.
Table 11. WEP Encryption Settings
Field Descriptions
Data Encryption Select the encryption key size from the drop-down list:
• 64-b
it WEP. Standard WEP encryption, using 40/64-bit encryption.
• 128-b
it WEP. Standard WEP encryption, using 104/128-bit encryption.
• 152-bit WEP. Proprietary WEP encryption mode, using 128+24 bits encryption. This
mode functions only with other wireless station that support this mode.
Passphrase Enter a passphrase. The passphrase length needs to
be between 8 and 63 characters
(inclusive). The secret passphrase allows you to automatically generate the keys by
clicking Generate Keys. The default passphrase is sharedsecret.
You can display the actual passphrase by selecting the Sh
ow Passphrase in Clear Text
radio button.
Encryption Key
(Key1–Key4)
Either manually enter a key or allow the key to
be automatically generated by clicking
Generate Key.
• For ASCII format, depending on the key size selected, the manually entered encryption
key ne
eds to have a length of 5 (64-bit WEP), 13 (128-bit WEP), or 16 (152-bit WEP)
characters.
• For HEX format, depending on the key size selected, the manually entered or
automatical
ly generated encryption key needs to have a length of 10 (64-bit WEP),
26 (128-bit WEP), or 32 (152-bit WEP) characters.
Note: Wireless stations need to use the key
to access the wireless access point.
Note: Not all wireless adapters support passphrase key generation.
Show Passphrase in
Cl
ear Text
Select the Yes radio button to display the actual passphrase in the Passphrase field. The
default setting is No.

NETGEAR WNDAP360 Specifications

General

VLAN support	Yes
Frequency band	2.4 - 5 GHz
Number of users	50 user(s)
Cabling technology	10/100/1000BASE-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Antenna connector type	SMA
Antenna gain level (max)	5 dBi
Weight (imperial)	1.93 lbs
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE802.1x
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, EAP, EAP-TLS, EAP-TTLS, PEAP, SSH, SSL/TLS, TTLS, WEP, WPA, WPA2
Power requirements	12 VDC, 1A
Power consumption (typical)	10.51 W
Minimum system requirements	Internet Explorer 6.0, Mozilla Firefox 1.5
Compatible operating systems	- Windows Vista, XP, 2000, 98, Me - Mac OS - UNIX - Linux
Internal	No
LED indicators	LAN
Cable lock slot type	Kensington

Weight and Dimensions

Height	54.76 mm
Weight	878 g
Dimensions (WxDxH)	253.75 x 253.76 x 54.76 mm
