MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 9
Figure 1-8 Schematic Diagram of MX60 Subscriber Line Connection
Figure 1-9 MX60 Back Panel-AC
Figure 1-10 MX60 Back Panel-DC
Table 1-14 Description of MX60 Back Panel
Indicator, see Table 1-15 for description
Configuration interface (CON), Ethernet lines used for local management and debugging
Two 10/100 Mbps Ethernet ports (RJ45). They share one IP address, which by default is
192.168.2.240, and you can change it on Basic > Network page.
AC power socket, 100-240 VAC voltage input.
DC power socket, -48 VDC input.
