MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 57
2.7.3 Management System Type
After login, click Advanced > System to open this interface.
Figure 2-41 SNMP Configuration Interface
Table 2-23 SNMP Configuration Parameters
Name
Description
Signaling port
Enter the SNMP local port. The default value is 2700.
If SNMP is selected, the following three parameters need to be specified.
Server
Enter the address of the SNMP server.
Trap port
Enter the port number of the SNMP server. The default value is 162.
Notification interval
The default value is 900 seconds.
Figure 2-42 TR069 Configuration Interface
