2.4.2 Subscriber Line Features
The content below is only applicable to gateways with FXS ports.
After login, click Line > Feature to open the configuration interface.
Figure 2-29 Subscriber Line Features Configuration Interface
Table 2-12 Subscriber Line Features Configuration Parameters
Name
Description
Phone ID
Fill in the port number associated with this port. “FXS-n” corresponds to the Line > Phone
Number > ID n.
Phone number
Fill in the number associated with this port.
Display as
Fill in the display name which will be contained in the From field of SIP message. e.g. From: "Bob
" <sip:8000@127.0.0.1>;tag=14340047091433920745-1, Bob is the display name.
Local SIP port
This parameter is displayed only when Multi port is selected in page Advanced > SIP. Set the port
used for receiving and sending SIP messages associated with the line.
If this parameter is not specified, the local port configured in Basic > SIP is used.
Note: This parameter is displayed only when Multi port is checked on Advanced > SIP page.
Registration
Select if this line is required to register to a soft switch. This is selected by default.
User name
If Registration is selected, users must enter the user name for registering the line here.
This is not mandatory. If this parameter remains blank, the phone number of the extension set is
used.
Registrar
password
If Registration is selected, users must enter the authentication password for registering of this line
here.
