Nexo NXAMP 4X4 - Page 117

26
NXAMP4x4
REF NO.
PART NO. DESCRIPTION REMARKS
QTY RANK
CN805 -- FASTEN TERMINAL 16611BL-2 (WA76770)
-808 -- FASTEN TERMINAL 16611BL-2 (WA76770)
CN809 -- CONNECTOR BASE POST PH 16P TE (VF28340) 01
CN810 -- CONNECTOR BASE POST PH 4P TE (VB39000) 01
D701 -- DIODE 1SS355 TE-17 (VT33290) 01
-708 -- DIODE 1SS355 TE-17 (VT33290) 01
D801 -- DIODE 1SS355 TE-17 (VT33290) 01
-804 -- DIODE 1SS355 TE-17 (VT33290) 01
IC701 -- IC NJM2068M-D(TE2) OP AMP (X3505A0) 02
IC702 -- IC NJM2068M-D(TE2) OP AMP (X3505A0) 02
IC801 -- IC NJM2068M-D(TE2) OP AMP (X3505A0) 02
IC802 -- IC NJM2068M-D(TE2) OP AMP (X3505A0) 02
JK701 -- CANNON CONNECTOR JACK NC3FBV1 CH1 INPUT (V986210) 05
JK702 -- CANNON CONNECTOR JACK NC3FBV1 CH2 INPUT (V986210) 05
JK703 -- CANNON CONNECTOR JACK NC3FBV1 CH3 INPUT (V986210) 05
JK704 -- CANNON CONNECTOR JACK NC3FBV1 CH4 INPUT (V986210) 05
JK705 -- CANNON CONNECTOR JACK NC3MBV CH1 LINKOUT (WJ45920) 06
JK706 -- CANNON CONNECTOR JACK NC3MBV CH2 LINKOUT (WJ45920) 06
JK707 -- CANNON CONNECTOR JACK NC3MBV CH3 LINKOUT (WJ45920) 06
JK708 -- CANNON CONNECTOR JACK NC3MBV CH4 LINKOUT (WJ45920) 06
K801 -- TERMINAL PLATE B88 (WE67930)
L801 -- COIL 1.9uH 15x10 (WD40870)
-804 -- COIL 1.9uH 15x10 (WD40870)
Q801 -- DIGITAL TRANSISTOR KRC105S-RTK/P (WS50920)
-804 -- DIGITAL TRANSISTOR KRC105S-RTK/P (WS50920)
R701 -- THICK FILM RESISTOR (CHIP) 10K 1/10W D (RD55710) 01
-708 -- THICK FILM RESISTOR (CHIP) 10K 1/10W D (RD55710) 01
R709 -- THICK FILM RESISTOR (CHIP) 2.0K 1/10W D (RD55620)
-716 -- THICK FILM RESISTOR (CHIP) 2.0K 1/10W D (RD55620)
R717 -- CARBON RESISTOR (CHIP) 120 1/16W J (RD35512) 01
-720 -- CARBON RESISTOR (CHIP) 120 1/16W J (RD35512) 01
R801 -- METAL OXIDE FILM RESISTOR 2.2 3W J (WK91630) 01
-804 -- METAL OXIDE FILM RESISTOR 2.2 3W J (WK91630) 01
R805 -- METAL OXIDE FILM RESISTOR 4.7 3W J (WD40710)
-808 -- METAL OXIDE FILM RESISTOR 4.7 3W J (WD40710)
R809 -- FLAME PROOF C. RESISTOR 4.7 1/4W J (HV75347) 01
-812 -- FLAME PROOF C. RESISTOR 4.7 1/4W J (HV75347) 01
R813 -- CARBON RESISTOR (CHIP) 33K 1/16W D (RF45733) 01
-815 -- CARBON RESISTOR (CHIP) 33K 1/16W D (RF45733) 01
R816 -- CARBON RESISTOR (CHIP) 4.7K 1/16W D (RF45647)
R817 -- CARBON RESISTOR (CHIP) 33K 1/16W D (RF45733) 01
-819 -- CARBON RESISTOR (CHIP) 33K 1/16W D (RF45733) 01
R820 -- CARBON RESISTOR (CHIP) 4.7K 1/16W D (RF45647)
R821 -- CARBON RESISTOR (CHIP) 33K 1/16W D (RF45733) 01
-823 -- CARBON RESISTOR (CHIP) 33K 1/16W D (RF45733) 01
R824 -- CARBON RESISTOR (CHIP) 4.7K 1/16W D (RF45647)
R825 -- CARBON RESISTOR (CHIP) 33K 1/16W D (RF45733) 01
-827 -- CARBON RESISTOR (CHIP) 33K 1/16W D (RF45733) 01
R828 -- CARBON RESISTOR (CHIP) 4.7K 1/16W D (RF45647)
R829 -- CARBON RESISTOR (CHIP) 18 1/16W J (RD35418) 01
-832 -- CARBON RESISTOR (CHIP) 18 1/16W J (RD35418) 01
R837 -- FLAME PROOF C. RESISTOR 1.0 1/4W J (HV75310) 01
-840 -- FLAME PROOF C. RESISTOR 1.0 1/4W J (HV75310) 01
RY801 -- RELAY DC DI24D1-O(M) (WJ56900) 05
-808 -- RELAY DC DI24D1-O(M) (WJ56900) 05
SP801 -- RECEPTACLE CONNECTOR 4P NL4MD-H Speakon A (V818170) 06
SP802 -- RECEPTACLE CONNECTOR 4P NL4MD-H Speakon B (V818170) 06
SP803 -- RECEPTACLE CONNECTOR 4P NL4MD-H Speakon C (V818170) 06
SP804 -- RECEPTACLE CONNECTOR 4P NL4MD-H Speakon D (V818170) 06
W701 -- CONNECTOR ASSEMBLY SIG-IN B&C 13P 330mm (WK02070)
W801 -- CONNECTOR ASSEMBLY OUTPS B&C TUBE 5P 420mm (WK14200)
W802 -- CONNECTOR ASSEMBLY B&C 1P 530mm BK (WK16820) 03
W803 -- CONNECTOR ASSEMBLY B&C 1P 650L BK (WM04880)
W804 -- CONNECTOR ASSEMBLY B&C 1P 650L BK (WM04880)
W805 -- CONNECTOR ASSEMBLY B&C 1P 530mm BK (WK16820) 03
XX801 -- CURRENT SENSOR L18P020D15 (WJ45850)
-804 -- CURRENT SENSOR L18P020D15 (WJ45850)
* WT661200 CIRCUIT BOARD NX-DFLT (YC233A0)
-- LED SPACER LDS-45B L=4.5 (WJ35070)
INAN, OUTANH and NX-DFLT
✽ : New Parts RANK: Japan only
