27
NXAMP4x4
REF NO.
PART NO. DESCRIPTION REMARKS
QTY RANK
C001 -- CERAMIC CAPACITOR-F (CHIP) 0.1uF 50V Z (US06510)
-011 -- CERAMIC CAPACITOR-F (CHIP) 0.1uF 50V Z (US06510)
CN001 -- CONNECTOR PHEC 80P SE (WT66950)
K001 -- SCREW TERMINAL M3 8.3x13 M1698 (BB07136)
K002 -- SCREW TERMINAL M3 8.3x13 M1698 (BB07136)
LD001 -- LED GREEN SLR-332MG3F (V561690)
R001 -- CARBON RESISTOR (CHIP) 56 1W J (WT66810)
-010 -- CARBON RESISTOR (CHIP) 56 1W J (WT66810)
R011 -- CARBON RESISTOR (CHIP) 100 1/16W J (RD35510)
R012 -- CARBON RESISTOR (CHIP) 100 1/16W J (RD35510)
R013 -- CARBON RESISTOR (CHIP) 33 1/16W J (RD35433)
WJ971500 CIRCUIT BOARD OPT-AN (I891)(X8711E0) 16
-- CIRCUIT BOARD PN-AN (WJ97170)(X8711E0)(WJ97130) 20
* WJ971401 CIRCUIT BOARD RS232-GPI (WJ97170)(X8711E0) 16
-- CIRCUIT BOARD LCD SPACER (WJ97170)(X8711E0)(WK62420) 08
C001 -- CERAMIC CAPACITOR-B (CHIP) 0.01uF 50V K (US06410) 01
-003 -- CERAMIC CAPACITOR-B (CHIP) 0.01uF 50V K (US06410) 01
C004 -- CERAMIC CAPACITOR-B (CHIP) 0.047uF 16V K (US03447) 01
C005 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
-009 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C010 -- CERAMIC CAPACITOR-SL(CHIP) 100pF 50V J (US06210) 01
C201 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
-203 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
CN001 -- FFC CONNECTOR 52271-3079 P=1mm (WJ85350) 03
CN002 -- CONNECTOR MTLW 16P (WK74020)
CN201 -- FFC CONNECTOR 52271-3079 P=1mm (WJ85350) 03
CN202 -- D SUB CONNECTOR J 9P RS232 (WK51820) 06
CN203 -- D SUB CONNECTOR J 25P GPI (WK51830)
CN301 -- CONNECTOR FMN 40P (WC19900)
CN302 -- CONNECTOR PLUG PHEC 80P TE (V915200) 05
EC001 -- ROTARY ENCODER EC11B20204AP ENCODER (WK80260) 05
EM201 -- EMI FILTER (CHIP) NFM3DCC101U1H3L (VQ76140) 01
EM202 -- LC FILTER NFA31CC101S1E4D (WC39150) 01
-205 -- LC FILTER NFA31CC101S1E4D (WC39150) 01
IC001 -- IC SN74LV541APWRBUS B BUFFER/DRIVER (X5966A0) 01
IC002 -- IC 74HCT273PW,118 D-F D-TYPE FLIP FLOP (X8681A0) 03
IC003 -- IC 74HCT273PW,118 D-F D-TYPE FLIP FLOP (X8681A0) 03
IC004 -- IC 74HCT4514PW,118 4T DECODER/DEMULTIPLEXER
(X8630A0)
-007 -- IC 74HCT4514PW,118 4T DECODER/DEMULTIPLEXER
(X8630A0)
LD001 -- LED GREEN (CHIP) GREEN SML-512MW SIGNAL-CH1 (WJ83350) 01
LD002 -- LED GREEN (CHIP) GREEN SML-512MW SIGNAL-CH2 (WJ83350) 01
LD003 -- LED GREEN (CHIP) GREEN SML-512MW SIGNAL-CH3 (WJ83350) 01
LD004 -- LED GREEN (CHIP) GREEN SML-512MW SIGNAL-CH4 (WJ83350) 01
LD005 -- LED YELLOW (CHIP) YELLOW SML-512WW PROTECT-CH1 (WG96210) 01
LD006 -- LED YELLOW (CHIP) YELLOW SML-512WW PROTECT-CH2 (WG96210) 01
LD007 -- LED YELLOW (CHIP) YELLOW SML-512WW PROTECT-CH3 (WG96210) 01
LD008 -- LED YELLOW (CHIP) YELLOW SML-512WW PROTECT-CH4 (WG96210) 01
LD009 -- LED RED (CHIP) SML-512UW PEAK-CH1 (WD11160) 01
LD010 -- LED RED (CHIP) SML-512UW PEAK-CH2 (WD11160) 01
LD011 -- LED RED (CHIP) SML-512UW PEAK-CH3 (WD11160) 01
LD012 -- LED RED (CHIP) SML-512UW PEAK-CH4 (WD11160) 01
LD013 -- LED GREEN (CHIP) GREEN SML-512MW POWER (WJ83350) 01
LD014 -- LED YELLOW (CHIP) YELLOW SML-512WW STANDBY (WG96210) 01
LD015 -- LED RED (CHIP) SML-512UW AMP-PROTECT (WD11160) 01
LD016 -- LED WHITE (CHIP) WHITE SMLE12WBC7W CH1-VOL1 (WK27910)
LD017 -- LED WHITE (CHIP) WHITE SMLE12WBC7W CH1-VOL2 (WK27910)
LD018 -- LED WHITE (CHIP) WHITE SMLE12WBC7W CH1-VOL3 (WK27910)
LD019 -- LED WHITE (CHIP) WHITE SMLE12WBC7W CH1-VOL4 (WK27910)
LD020 -- LED WHITE (CHIP) WHITE SMLE12WBC7W CH1-VOL5 (WK27910)
LD021 -- LED WHITE (CHIP) WHITE SMLE12WBC7W CH1-VOL6 (WK27910)
LD022 -- LED WHITE (CHIP) WHITE SMLE12WBC7W CH1-VOL7 (WK27910)
LD023 -- LED WHITE (CHIP) WHITE SMLE12WBC7W CH1-VOL8 (WK27910)
LD024 -- LED WHITE (CHIP) WHITE SMLE12WBC7W CH1-VOL9 (WK27910)
LD025 -- LED WHITE (CHIP) WHITE SMLE12WBC7W CH1-VOL10 (WK27910)
LD026 -- LED WHITE (CHIP) WHITE SMLE12WBC7W CH1-VOL11 (WK27910)
LD027 -- LED WHITE (CHIP) WHITE SMLE12WBC7W CH1-VOL12 (WK27910)
LD028 -- LED WHITE (CHIP) WHITE SMLE12WBC7W CH1-VOL13 (WK27910)
NX-DFLT, OPT-AN, PN-AN and RS232-GPI
✽ : New Parts RANK: Japan only
